  • Page 1 ORTAL TECHNICAL GUIDE December 2015...
  • Page 2 Balanced Flue Horizontal. ( Up and out ) Balanced Flue Vertical Flue Renovation Ortal have now obtained certification for all the CE marked fires to use flexible flue liners - with certain conditions. The conditions are; For use only with renovation or adaptation...
  • Page 3 Please read these instructions carefully before installation or use, and leave with the customer for storage in a safe place for future reference. Ortal Technical Guide December 2015...
  • Page 4: Table Of Contents

    This manual covers the following appliances: Clear 40 RS/LS/TS/Tunnel, Stand Alone 40 TS, Clear 40 H RS/LS/TS/Tunnel, Clear 40H 70 LS/TS/Tunnel, Clear 75 RS/LS/TS, Stand Alone 75 ITS, Minimal 75, Space Creator 75, Clear 75x65 /Tunnel, Stand Alone 75x65 Curve /Tunnel,...
  • Page 5: Important Safety Notice

    Do not place any articles within 30cm of this appliance as this may result in damage to the articles. The installation must be carried out in accordance with the following regulations: Ortal Technical Guide December 2015...
  • Page 6: General Fitting Information

    Receiver: 4 x AA. Transmitter: 3 x AAA If the Flame Supervision Device is extinguished either intentionally or unintentionally, no attempt should be made to re-light the gas until at least 3 minutes have elapsed. Ortal Technical Guide December 2015...
  • Page 7: Ventilation

    300mm should be given all round the stove before combustible materials may be used in the wall construction. If the appliance has to be located in an opening, a minimum clearance of 50mm should be allowed to non-combustible materials. Ortal Technical Guide December 2015...
  • Page 8 If the outer wall surface is constructed of combustible material, a non-combustible plate should be fitted behind the terminal projecting 25mm beyond the external edges of the terminal. Ortal Technical Guide December 2015...
  • Page 9 Ortal Technical Guide December 2015...
  • Page 10: Commissioning The Appliance

    Please ventilate the room. Also please note that during this initial burning period, a grey dust deposit will be formed the inside glass, please clean this before leaving the appliance with customer. Ortal Technical Guide December 2015...
  • Page 11: Servicing Instructions

    Check the flue joints are secure, including those in voids, and that the flue is working satisfactorily. Check that there are no flue products leaking from the appliance. parts need be replaced only genuine manufacturer parts, non-standard parts will invalidate guarantee and may be dangerous. Ortal Technical Guide December 2015...
  • Page 12: Spare Parts

    Ortal Technical Guide December 2015...
  • Page 13: Countries Of Destination / Gas Categories

    Ortal Technical Guide December 2015...
  • Page 14 Ortal Technical Guide December 2015...
  • Page 15 Ortal Technical Guide December 2015...
  • Page 16: Instructions For Changing The Burner From Natural Gas To Lpg

    Ortal Technical Guide December 2015...
  • Page 17 Ortal Technical Guide December 2015...
  • Page 18 Ortal Technical Guide December 2015...
  • Page 19 Ortal Technical Guide December 2015...
  • Page 20 Ortal Technical Guide December 2015...
  • Page 21: Technigas Ce Approval Test Results

    Ortal Technical Guide December 2015...
  • Page 22: Contents - Double Step Burner (D)

    Ortal Technical Guide December 2015...
  • Page 23: Minimum Clearances To Combustible Materials

    Ortal Technical Guide December 2015...
  • Page 24 6mm min. 6mm Non-combustible materials: Materials applicable for the installation of Ortal fireplaces within the specified clearance dimensions are described as non-combustible mate- rials. A suitable material is Skamotec 225 board. Suitable access to permit examination of the flue joints at service should be provided.
  • Page 25 TS Example shown 1000 mm 1000 mm Clear Front Min 50 mm Min 50 mm Min 50 mm 1000 mm All other models Drawing NOT to scale. All dimensions in mm. August 2014 Ortal Technical Guide December 2015...
  • Page 26 300mm Min. 6mm Clear Front Non-combustible materials: Materials applicable for the installation of Ortal fireplaces within the specified clearance dimensions are described as non-combustible materials. A suitable material is Skamotec 225 board. Suitable access to permit examination of the flue joints at service should be provided.
  • Page 27 TS Example shown 1000 mm 1000 mm Clear Front Min 50 mm Min 50 mm Min 50 mm 1000 mm All other models Drawing NOT to scale. All dimensions in mm. August 2014 Ortal Technical Guide December 2015...
  • Page 28 Min 225 mm Non-combustible materials: Materials applicable for the installation of Ortal fireplaces within the specified clearance dimensions are described as non-combustible materials. A suitable material is Skamotec 225 board. Suitable access to permit examination of the flue joints at service should be provided.
  • Page 29 1000mm 1000mm Non-combustible materials: Materials applicable for the installation of Ortal fireplaces within the specified clearance dimensions are described as non-combustible materials. A suitable material is Skamotec 225 board. Suitable access to permit examination of the flue joints at service should be provided.
  • Page 30 1000mm 1000mm Non-combustible materials: Materials applicable for the installation of Ortal fireplaces within the specified clearance dimensions are described as non- combustible materials. A suitable material is Skamotec 225 board. Suitable access to permit examination of the flue joints at service should be provided.
  • Page 31 1000mm Non-combustible materials: Materials applicable for the installation of Ortal fireplaces within the specified clearance dimensions are described as non- combustible materials. A suitable material is Skamotec 225 board. Suitable access to permit examination of the flue joints at service should be provided.
  • Page 32 NOT recommended. Min 250mm Non-combustible materials: Materials applicable for the installation of Ortal fireplaces within the specified clearance dimensions are described as non- combustible materials. A suitable material is Skamotec 225 board. Suitable access to permit examination of the flue joints at service should be provided.
  • Page 33 If you wish to install a flat screen television or similar electronic device above your Ortal gas fire, here are some things you should consider. Most TV manufacturers have specified in their instructions that the TV should not be installed on, near or above a heat source. Ul- timately, the decision of the TV location rests solely with the house holder.
  • Page 34 Min 50mm clearance all round the Min 50mm Min 300mm Offset only allowed on Minimum 25mm thermal vertical flue. insulation sheet which can withstand 120 °C FLAT FIREPLACE Use heat resistant cable Dimensions in mm Ortal Technical Guide December 2015...
  • Page 35 Ortal Technical Guide December 2015...
  • Page 36 Ortal Technical Guide December 2015...
  • Page 37: English Branches

    Ortal Technical Guide December 2015...
  • Page 38 Ortal Technical Guide December 2015...
  • Page 39 Ortal Technical Guide December 2015...
  • Page 40 Ortal Technical Guide December 2015...
  • Page 41 Ortal Technical Guide December 2015...
  • Page 42: Small Pebbles

    Ortal Technical Guide December 2015...
  • Page 43 Ortal Technical Guide December 2015...
  • Page 44 Ortal Technical Guide December 2015...
  • Page 45 Ortal Technical Guide December 2015...
  • Page 46: Large Pebbles

    Ortal Technical Guide December 2015...
  • Page 47 Ortal Technical Guide December 2015...
  • Page 48 Ortal Technical Guide December 2015...
  • Page 49 Ortal Technical Guide December 2015...
  • Page 50: Refractory Clay Logs (6 Piece Set)

    English Logs Ortal Technical Guide December 2015...
  • Page 51 English Logs Ortal Technical Guide December 2015...
  • Page 52 English Logs Ortal Technical Guide December 2015...
  • Page 53 English Logs Ortal Technical Guide December 2015...
  • Page 54 English Logs Ortal Technical Guide December 2015...
  • Page 55: Flue Design Options

    V = Total vertical height H = Total horizontal …...distance X = Not permitted Ortal Technical Guide December 2015...
  • Page 56 130/200 flue size is used. To use a 100/150 flue a USVK10 13 reducer will be required. This must be installed above the USA adaptor. V = Total vertical height H = Total horizontal …...distance X = Not permitted Ortal Technical Guide December 2015...
  • Page 57 V = Total vertical height H = Total horizontal …...distance X = Not permitted Ortal Technical Guide December 2015...
  • Page 58 V = Total vertical height H = Total horizontal …...distance X = Not permitted Ortal Technical Guide December 2015...
  • Page 59 V = Total vertical height H = Total horizontal …...distance X = Not permitted Ortal Technical Guide December 2015...
  • Page 60 Ortal Flue Design Options The permitted flue configurations and flue restrictor sizes are as shown in the tables. V = total vertical height H =total horizontal distance X = configuration not permitted There should be a minimum of 1m vertical connected to the fire before any bends. The only exception to this is for a vertical flue and termination, where it is permissible to connect 2 x 45 degree bends directly to a USA adaptor above the fire to offset the flue.
  • Page 61: Troubleshooting

    Make sure that the burner is burning correctly. The flame should be even across the top of the burner before any coals are placed on top. Ortal Technical Guide December 2015...
  • Page 62: Operating Instructions

    Ortal Technical Guide December 2015...
  • Page 63 Ortal Technical Guide December 2015...
  • Page 64 Ortal Technical Guide December 2015...
  • Page 65 Ortal Technical Guide December 2015...
  • Page 66 Ortal Technical Guide December 2015...
  • Page 67 Ortal Technical Guide December 2015...
  • Page 68 Ortal Technical Guide December 2015...
  • Page 69 Ortal Technical Guide December 2015...
  • Page 70 Ortal Technical Guide December 2015...
  • Page 71 Ortal Technical Guide December 2015...
  • Page 72 Ortal Technical Guide December 2015...
  • Page 73 Ortal Technical Guide December 2015...
  • Page 74 Ortal Technical Guide December 2015...
  • Page 75 Ortal Technical Guide December 2015...
  • Page 76 Robeys Ltd Riverside Works, Goods Road Industrial Estate, Belper, Derbyshire. DE65 1UU Tel 01773 820940 Fax 01773 820477 e-mail: info@robeys.co.uk www.robeys.co.uk...
