Page 1: Installation Instructions
INSTALLATION INSTRUCTIONS USER GUIDE Tilted wall cooker hood HT90GHB2 model GB IE... -
Page 3: Table Of Contents
CONTENTS Introduction Safety and warnings Installation instructions About your cooker hood – Energy efficiency Operating instructions Cleaning and maintenance Parts and accessories Manufacturer’s Warranty Customer Care ImpORTANT! Registration SAVE THESE INSTRUCTIONS Register your product with us so we can The models shown in this user guide may provide you with the best service possible. -
Page 5: Introduction
INTROduCTION Thank you for purchasing a Fisher & Paykel product. Thousands of hours go into the design, engineering, testing and perfecting of each Fisher & Paykel appliance. The care and attention given to creating these beautiful products doesn’t stop once it has found its home with you. This use and care manual will answer most of your questions about the set-up, use and on-going maintenance of your Fisher &... -
Page 6: Safety And Warnings
SafETy aNd waRNINGS waRNING! weight Hazard The cooker hood is heavy. Please ensure adequate care is taken when installing the cooker hood to prevent personal injury. The cooker hood must be installed onto a solid 34.5 kg wall, stud, beam or truss. weight of the product is 34.5 kg. - Page 7 SafETy aNd waRNINGS and in compliance with any applicable local building and electricity regulations. failure to install the appliance correctly could invalidate any warranty or liability claims. • If the power supply cable is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person in order to avoid a hazard.
- Page 8 SafETy aNd waRNINGS • when the cooker hood is turned on at the same time as other appliances powered by energy other than electricity, the air outlet must not be greater than 4 Pa (4x10-5 bar). • The minimum distance between the hob surface and the base of the cooker hood shall be 400 mm or 650 mm if installed over a gas hob.
- Page 9 SafETy aNd waRNINGS • during climatic conditions causing electrical interference, it is possible that the device may stop working. By switching the device off and on the device will resume normal operation safety. • during an electrostatic discharge (ESd) it is possible that the device will stop working.
-
Page 10: Installation Instructions
INSTaLLaTION INSTRuCTIONS unpacking your cooker hood... - Page 11 INSTaLLaTION INSTRuCTIONS Contents of packaging INSTALLATION INSTRUCTIONS USER GUIDE Tilted wall cooker hood HT90GHB2 model GB IE Cooker hood Installation instructions Chimney User guide manual Upper chimney Chimney bracket Upper chimney bracket 60 mm screws 30 mm screws 10 mm screws and wall plugs...
- Page 12 INSTaLLaTION INSTRuCTIONS Product dimensions Power cord location Ø...
- Page 13 INSTaLLaTION INSTRuCTIONS HT90GHB2 PROduCT dIMENSIONS Overall height of product 800 – 1140 Overall width of product Overall depth of product Height of hood Width of flue Depth of flue Distance from centre of ducting outlet to back of product Distance from centre of ducting outlet to side of flue...
- Page 14 INSTaLLaTION INSTRuCTIONS Height of cooker hood MINIMuM CLEaRaNCES Installation height Ducted min. 840 – max. 1140 Recirculation min. 880 – max. 1140 Height top of hob to base of product Electric hob min. 400 Gas hob min. 650...
- Page 15 INSTaLLaTION INSTRuCTIONS Venting options Attention should be given to ensure that any applicable regulations concerning the discharge of exhaust air are fulfilled. The cooker hood can be installed to operate with the exhaust air ducted externally from the kitchen, or installed to operate with the exhaust air recirculating within the kitchen. Ducted For ducted installation it is recommended that 150 mm diameter, rigid or semi-rigid ducting is used.
- Page 16 INSTaLLaTION INSTRuCTIONS Installation WARNING! This product is heavy and requires two persons for installation. WARNING! failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. The manufacturer is not liable for any damage caused by not following these instructions. Preparing for installation: Before installing your cooker hood: Please read the instructions carefully.
- Page 17 INSTaLLaTION INSTRuCTIONS 250 mm Upper chimney bracket attachment points Chimney bracket attachment points 235 mm Upper hood attachment points 240 mm 270 mm Internal hood attachment points 250 mm Fig.2...
- Page 18 INSTaLLaTION INSTRuCTIONS Fig.3...
- Page 19 INSTaLLaTION INSTRuCTIONS Attach hood to wall Open the front panel on the hood and remove the filter as shown in figures 4 – 6. ● ● Fig.4 Fig.5 Fig.6 Hang hood off upper hood mounting screw with 2 mm gap. Hang off the keyhole ●...
-
Page 20: About Your Cooker Hood - Energy Efficiency
COOkER HOOd – ENERGy EffICIENCy Product fiche EN61591 MOdEL HT90GHB2 Annual Energy Consumption (kWh/annum) 32.2 Time Increase Factor Energy Efficiency Index 52.8 Energy Efficiency Class Fluid Dynamic Efficiency 28.5 Fluid Dynamic Efficiency Class Lighting Efficiency 28.7 Lighting Efficiency Class Grease Filtering Efficiency 91.2... -
Page 21: Operating Instructions
OPERaTING INSTRuCTIONS Touch control panel CONTROL PaNEL fEaTuRES Increase Press once to adjust the light to the lighting level highest level. The icon illuminates red when on the highest level. Press and hold to progressively increase the light level. Reduce Press once to adjust the light to lighting level the lowest level. -
Page 22: Cleaning And Maintenance
CLEaNING aNd MaINTENaNCE ImpORTANT! Never use abrasive or oil based cleaners Maintenance Before performing any cleaning or maintenance on your cooker hood, ensure that the power supply is switched off to the hood. The cooker hood should be cleaned regularly using a mild, liquid detergent to avoid a build-up of grease occurring. - Page 23 CLEaNING aNd MaINTENaNCE Carbon filter – for use in recirculation mode Active carbon filters are disposable items designed to remove grease and odours from cooking vapours before the air is channelled back into the kitchen. The active carbon filter must be replaced periodically to work properly, at least once every three months, depending on the frequency of use of the cooker hood.
-
Page 24: Parts And Accessories
PaRTS aNd aCCESSORIES ITEM REfERENCE NuMBER LED bulb x2 792556 Aluminium filter 791761 Recirculation carbon filter 50031 Recirculation diverter 50032 Ducting 150 mm kit (eaves) 50033 Ducting 150 mm kit (wall) 50034... -
Page 25: Manufacturer's Warranty
MaNufaCTuRER’S waRRaNTy You automatically receive a 2 year Manufacturer’s Warranty with the purchase of this Tilted wall cooker hood covering parts and labour for servicing within the United Kingdom and Ireland. fisher & Paykel undertakes to: Repair or, at its option, replace without cost to the owner either for material or labour any part of the product, the serial number of which appears on the product, which is found to be defective within TWO YEARS of the date of purchase. -
Page 26: Customer Care
CuSTOMER CaRE Before you call for service or assistance... Check the things you can do yourself. Refer to your user guide and check that: Your product is correctly installed. You are familiar with its normal operation. If after checking these points you still need assistance or parts, please refer to your nearest Authorised Service Centre, Customer Care, or contact us through our local website listed on the back cover. - Page 27 CuSTOMER CaRE Complete and keep for safe reference: Model Serial No. Purchase Date Purchaser Dealer Suburb Town Country...
-
Page 28: Www.fisherpaykel.com
www.fisherpaykel.com Copyright © Fisher & Paykel 2015. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your dealer to ensure this booklet correctly describes the product currently available.
