Product Specifications

See product specification sheets for complete specification
listings.
Control 12C-VA
Components: 76 mm (3 in) full-range driver
1
Frequency Range : 68 Hz - 17 kHz
Power Capacity (low-Z): 40 W Cont. Program
20 W Cont. Pink Noise
2
Sensitivity : 84 dB
3
Coverage : 130˚
Max. SPL: 97 dB @ 1m ave., 103 dB peak
Nominal Impedance: 8 ohms (in direct/bypass 8Ω setting)
Transformer Taps: 15W, 7.5W, 3.8W @ 70V & 100V;
plus 1.9W @ 70V
Control 14C-VA
Components: 100 mm (4 in) LF driver
19 mm (3/4 in) HF driver
1
Frequency Range : 74 Hz - 20 kHz
Power Capacity (low-Z): 60 W Cont. Program
30 W Cont. Pink Noise
2
Sensitivity : 87 dB
3
Coverage : 120˚
Max. SPL: 102 dB @ 1m ave., 108 dB peak
Nominal Impedance: 8 ohms (in direct/bypass 8Ω setting)
Transformer Taps: 25W, 12.5W, 6.3W @ 70V & 100V;
plus 3.2W @ 70V
Control 16C-VA
Components: 165 mm (6.5 in) LF driver;
19 mm (3/4 in) HF driver
1
Frequency Range : 62 Hz - 20 kHz
Power Capacity (low-Z): 100 W Cont. Program
50 W Cont. Pink Noise
2
Sensitivity : 91 dB
3
Coverage : 110˚
Max. SPL: 108 dB @ 1m ave., 116 dB peak
Nominal Impedance: 8 ohms (in direct/bypass 8Ω setting)
Transformer Taps: 30W, 15W, 7.5W @ 70V & 100V;
plus 3.8W @ 70V
1
Half-space (flush mounted in ceiling)
2
Continuous Pink Noise Rating is IEC-shaped pink noise with a 6 dB crest
factor for 100 hours continuously. Continuous Program Power is a
conservative expression of the system's ability tohandle normal speech and
music program material, and is defined as 3 dB above the Continuous Pink
Noise Rating.
3
Half-space (in ceiling) average 1 kHz to 16 kHz.
JBL Professional
8500 Balboa Blvd, P.O. Box 2200
Northridge, CA 91329 U.S.A.
Contribution of Each One-Third Octave
Frequency Band when Speaker is Driven
at Full Volume, measured at 4 meter dis-
tance (req' d in this manual by EN54-24)
9
Control 12C-VA
Freq (Hz) Value
500 57.4
630 57.2
800 57.4
1000 57.8
1250 57.4
1600 59.9
2000 58.9
2500 54.7
3150 57.3
4000 59.2
Control 14C-VA
Freq (Hz) Value
500 58.8
630 58.0
800 58.4
1000 58.1
1250 57.7
1600 59.1
2000 59.0
2500 58.6
3150 60.8
4000 62.8
Control 16C-VA
Freq (Hz) Value
500 62.5
630 62.3
800 63.7
1000 65.6
1250 62.2
1600 62.9
2000 63.8
2500 64.4
3150 63.7
4000 65.4
