Thank you for purchasing JBL Control Contractor ceiling
loudspeakers. Read through this manual to familiarize
yourself with the features, applications and precautions
before you use these products.
Product Descriptions
The JBL Control Contractor Control 10C-VA Series
of EN54-24 certified ceiling loudspeakers utilize
innovative design and materials to provide premium level
performance from compact in-ceiling speakers.
CONTROL 12C-VA - A 3" (75 mm) full-range driver to
provide high-fidelity full-range sound over an extremely
wide coverage area.
CONTROL 14C-VA - A wide bandwidth ceiling speaker
containing a co-axially mounted 4" (100 mm) woofer and
¾" (19 mm) soft-dome tweeter.
CONTROL 16C-VA - A wide bandwidth, high sensitivity,
extended bass ceiling speaker containing a co-axially
mounted 6.5" (165 mm) woofer and ¾" (19 mm) soft-
dome tweeter.

Product Feature Identification

Loudspeaker
Driver
Gland Nut
Seismic Tab
(secondary
support point)
Perforated
Press-In Grille
2
(Control 14C-VA Shown)
Zinc-Plated
Steel Backcan
Tap Selector for
70V/100V taps, 8Ω
direct and OFF
Attachment
Screws
Terminal Cover
Plate
(Ceramic
Terminal Block
Inside)
Rotating
Mounting Tabs
(dog-ears)
