PARTS LIST
ELECTRICAL-PARTS
REF.NO.
PART NO.
51
645 049 5847 ROD ANTENNA
61
645 049 5830 15P FILM CABLE,
645 037 8720 SW HOUSING,AC SW COVER(PA)
645 037 9451 SWITCH SS12J11G7,SS-12J11 G7(PA)
645 041 6453 4P 3 CORE SHIELD W,
645 017 0195 CABLE TIE 4",MOTOR
DISPLAY, CTL KEY P.W.BOARD ASSY
REF.NO.
PART NO.
71
614 319 6815 ASSY,PWB DISPLAY,
71
614 319 5245 ASSY,PWB DISPLAY,
C0102
403 060 6904 POLYESTER 3300P M 50V
C0202
403 060 6904 POLYESTER 3300P M 50V
CN011
645 026 8816 2P WAFFR
D0101
645 016 9250 RECTIFIER
D0302
645 041 4503 DIODE 1SS133
D0303
645 016 8956 SW DIODE 1N4148
D0304
645 016 8956 SW DIODE 1N4148
D0305
645 016 8956 SW DIODE 1N4148
D0317
645 016 8956 SW DIODE 1N4148
D0318
645 016 8956 SW DIODE 1N4148
D0319
645 016 8956 SW DIODE 1N4148
D0320
645 016 8956 SW DIODE 1N4148
D0321
645 016 8956 SW DIODE 1N4148
D0322
645 016 8956 SW DIODE 1N4148
D0323
645 016 8956 SW DIODE 1N4148
D0324
645 016 8956 SW DIODE 1N4148
D0402
645 041 4503 DIODE 1SS133
D0403
645 041 4503 DIODE 1SS133
D0404
645 016 8956 SW DIODE 1N4148
D0405
645 041 4503 DIODE 1SS133
D0406
645 016 8956 SW DIODE 1N4148
IC401
645 041 4435 IC LC72336 9557
L0401
645 026 7857 AXIAL INDUCTOR
LD401
645 049 5854 LCD DISPLAY
Q0303
645 041 4459 TR 2SA1522
Q0304
645 026 8540 TRANSISTOR,2SC3916
Q0305
645 026 8540 TRANSISTOR,2SC3916
Q0306
645 026 8540 TRANSISTOR,2SC3916
Q0307
645 026 8540 TRANSISTOR,2SC3916
Q0308
645 016 9205 TRANSISTOR
Q0309
645 016 9205 TRANSISTOR
Q0310
645 016 9205 TRANSISTOR
Q0311
645 016 9205 TRANSISTOR
Q0312
645 016 9205 TRANSISTOR
Q0401
645 016 9205 TRANSISTOR
Q0402
645 016 9205 TRANSISTOR
Q0403
645 016 9205 TRANSISTOR
Q0404
645 016 9205 TRANSISTOR
RX401
645 036 2170 REMOTE RECEIVER,
SW101
645 049 5670 SW SLIDE,L/R CH SS43D01M10
SW102
645 036 2002 SWITCH PUSH,
SW401
645 041 4596 TACT SW KTL-TC-0103,PRESET
SW402
645 041 4596 TACT SW KTL-TC-0103,BAND
SW403
645 041 4596 TACT SW KTL-TC-0103,TUNER
SW404
645 041 4596 TACT SW KTL-TC-0103,BACK
SW405
645 041 4596 TACT SW KTL-TC-0103,STOP
SW406
645 041 4596 TACT SW KTL-TC-0103,PLAY
SW407
645 041 4596 TACT SW KTL-TC-0103,TUNER
SW408
645 041 4596 TACT SW KTL-TC-0103,FWD
SW409
645 041 4596 TACT SW KTL-TC-0103,MEMORY
DESCRIPTION
CN501 TO CD MECHA
TAPE HEAD TO CNP701
DESCRIPTION
CTL KEY(Only initial)(AU)(XE)(PA)
CTL KEY(Only initial)(MX)(US)(CA)
INFRARED MODOULE
SBBS PS-22E08L-0 W/LOCK
REF.NO.
PART NO.
SW410
645 041 4596 TACT SW KTL-TC-0103,REPEAT
VR101
645 036 3122 ROTARY VR,XV0141GPVN20FS-
XT401
645 049 5861 CRYSTAL 4.5MHZ
645 049 5700 2P SHIELD WIRE AWG26,
645 049 5717 7P F WIRE UL,
645 049 5724 8P F WIRE UL,
645 049 5731 15P F WIRE UL,
645 049 5755 10P TML, 9 JIS D SH,
645 049 5755 10P TML, 9 JIS D SH,
645 049 5731 15P F WIRE UL,
CD SWITCH P.W.BOARD ASSY
REF.NO.
PART NO.
72
614 319 5252 ASSY,PWB CD SWITCH,
SW501
645 025 1818 MICRO SW LF-101-0,LF-101-0
CD MAIN/TUNER P.W.BOARD ASSY
REF.NO.
PART NO.
73
614 319 5238 ASSY,PWB CD MAIN/TU
73
614 319 6808 ASSY,PWB CD MAIN/TU
73
614 319 8031 ASSY,PWB CD MAIN/TU
C0110
403 057 3800 POLYESTER 0.1U M 50V,TU
C0111
403 125 5507 ELECT 1000U M 16V,TU
C0210
403 057 3800 POLYESTER 0.1U M 50V,TU
C0312
403 135 5702 ELECT 4700U M 25V,TU
C0501
403 057 3800 POLYESTER 0.1U M 50V,CD
C0502
403 057 3800 POLYESTER 0.1U M 50V,CD
C0519
403 059 4409 POLYESTER 2200P M 50V,CD
C0601
403 059 8902 POLYESTER 0.22U M 50V,CD
C0604
403 060 8908 POLYESTER 0.033U M 50V,CD
C0606
403 062 1105 POLYESTER 0.047U M 50V,CD
C0608
403 060 6904 POLYESTER 3300P M 50V,CD
C0609
403 058 6008 POLYESTER 0.15U M 50V,CD
C0612
403 056 8905 POLYESTER 1000P M 50V,CD
C0613
403 057 3800 POLYESTER 0.1U M 50V,CD
C0614
403 058 4004 POLYESTER 0.015U M 50V,CD
C0615
403 059 0708 POLYESTER 0.018U M 50V,CD
C0616
403 060 6904 POLYESTER 3300P M 50V,CD
C0621
403 060 6904 POLYESTER 3300P M 50V,CD
C0623
403 059 4409 POLYESTER 2200P M 50V,CD
C0625
403 060 8908 POLYESTER 0.033U M 50V,CD
C0630
403 057 1202 POLYESTER 0.01U M 50V,CD
C0817
403 058 1904 POLYESTER 1500P M 50V,TU
C0818
403 057 1202 POLYESTER 0.01U M 50V,TU
C0819
403 057 1202 POLYESTER 0.01U M 50V,TU
CF801
645 020 2988 CERAMIC DISCRIMINATOR
CF802
645 049 5762 CERAMIC FILTER
CF803
645 049 5762 CERAMIC FILTER
CF804
645 027 7672 CERAMIC FILTER
CN001
645 011 4533 2P WAFER,CNP1
CN002
645 011 4533 2P WAFER,CNP2
CN003
645 020 6771 2P WAFER,CNP3 BATT
CN004
645 016 9342 2P WAFER,CNP4
- 8 -
DESCRIPTION
CNP4 TO CN4
DISPLAY CNP8 TO MAIN CN8
DISPLAY CNP10 TO MAIN CN
DISPLAY CNP7 TO MAIN CN7
(MX)(US)(CA)
DISPLAY CNP5 TO MAIN CN5
(MX)(US)(CA)
DISPLAY CNP5 TO MAIN CN5
(AU)(XE)(PA)
DISPLAY CNP7 TO MAIN CN7
(AU)(XE)(PA)
DESCRIPTION
CD DOOR SW(Only initial)
DESCRIPTION
(Only initial)(MX)(US)(CA)
(Only initial)(AU)(XE)
(Only initial)(PA)
