PARTS LIST

EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE
IEC SYMBOL
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATE COMPONENTS IN WHICH SAFETY CAN
! ! !
OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED , USE ONLY THE REPLACEMENT PARTS
DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE DESIGNATED
IN THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO
DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING
THE PRODUCT TO THE CUSTOMER.
CAUTION :
Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50V and less than 1000µF of Ceramic type and Electrolytic type.
PACKING & ACCESSORIES
REF.NO.
PART NO.
645 036 3429 CAUTION SHEET(MX)(US)
645 049 6318 POLYFOAM TOP
645 049 6325 POLYFOAM BOTTOM
645 020 3626 POLBAG,FOR AC CORD(PA)(XE)(AU)
645 049 6349 CARTON BOX(MX)(US)
645 049 7186 CARTON BOX(AU)
645 049 7193 CARTON BOX(XE)
645 049 6370 CARTON BOX(CA)
645 049 8152 CARTON BOX(PA)
645 049 6356 INSTRUCTION MANUAL(MX)(US)
645 049 7162 INSTRUCTION MANUAL(AU)
645 049 7179 INSTRUCTION MANUAL(XE)
645 049 6363 INSTRUCTION MANUAL(CA)
645 049 8145 INSTRUCTION MANUAL(PA)
645 037 8454 AC LINE CORD,VDE APP(XE)
! ! !
645 037 9468 AC CORD SET,VDE APP(PA)
! ! !
645 038 2048 AC CORD SET,UL APP(MX)(CA)(US)
! ! !
645 022 1576 AC LINE CORD SET,SAA APP(AU)
! ! !
645 047 8703 REMOTE CONTROL, HANDSET
CABINET & CHASSIS
REF.NO.
PART NO.
1
645 049 5953 LID CASS(MX)(US)
1
645 049 5960 LID CASS(AU)(CA)(XE)(PA)
2
645 049 6240 CASS DOOR SPRING
3
645 049 6059 VOLUME KNOB,ROTARY
4
645 049 6189 VOLUME KNOB RING
5
645 049 6196 TUNING KNOB RING
6
645 049 5878 CABINET FRONT
7
645 025 1542 ASSY,GEAR CD DOOR
8
645 049 5557 ASSY MINI PANEL(PA)(XE)(AU)(CA)
8
645 049 5540 ASSY MINI PANEL(MX)(US)
11
645 049 6110 BUTTON SET,MEMO/PRESET/BAND
12
645 049 6073 TUNING BUTTON,UP/DOWN PUSH
13
645 049 6080 BASS BUTTON
14
645 049 6066 SLIDE KNOB,
15
645 049 6127 CASS BUTTON REC
16
645 049 6134 CASS BUTTON PLAY
17
645 049 6141 CASS BUTTON REW
18
645 049 6158 CASS BUTTON FFWD
19
645 049 6165 CASS BUTTON STOP/EJE
20
645 049 6172 CASS BUTTON PAUSE
21
645 049 6257 CASS BUTTON SHAFT
23
645 049 6486 HARD RUBBER,NO:RY-105112 DA11
24
645 049 6479 SOFT RUBBER,NO:RY-105118 DA11
25
645 025 2556 CD BRACKET 9503
26
645 049 6219 CD BRACKET,
27
645 049 6226 SW CD LOCKER,CD BKT F1Q61K

PRODUCT SAFETY NOTICE

DESCRIPTION
DESCRIPTION
FUNTION CD/TAPE/RADIO
NEVER TOUCH THE LENS
REF.NO.
PART NO.
28
645 025 2549 MAGNET NMB FERRITE CORES
29
645 025 2341 MAGNET FELT CD
30
645 049 6493 CD DOOR SPRING
31
645 049 5533 ASSY CD LID
34
645 049 6264 BKT PCB MOUNTING,MAIN PCB
35
645 049 8084 ASSY CABINET REAR,PA(PA)
35
645 049 5526 ASSY CABINET REAR
37
645 047 8758 BATTERY LID
38
645 049 6011 HANDLE
39
645 049 5915 SPK NET
40
645 049 5922 SPK PANEL FRONT
41
645 049 5496 ASSY BOX REAR L
42
645 049 5502 ASSY BOX REAR R
44
645 049 6462 CD MECHANISM DA11N
52
645 049 5786 BUZZER
53
645 049 5779 5" SPK,W/BLACK CAP
54
645 049 5694 2P J WIRE AWG22UL,SPK TO MAIN
55
645 049 6004 DISPLAY LENS,SANYO
56
645 049 5984 CASS DOOR LENS
57
645 026 6454 ASSY,CASS GEAR
58
645 049 7216 GRILL CLOTH,RC-801K-19(PA)(XE)
58
645 049 6516 GRILL CLOTH,RC-801K-19/UL(CA)
58
645 049 6509 GRILL CLOTH,RC-801E/UL
59
645 025 2587 HOLDER MAGNET
60
645 049 6233 BKT LCD DISPLAY
FIXING PARTS
REF.NO.
PART NO.
Y01
645 036 2644 SCR 3X8,CASS KEY SHAFT
Y02
645 016 5078 SCREW,MAIN PANEL
Y04
645 014 1911 SCREW,CD KEY BD TO F PANEL
Y06
645 016 5078 SCREW,CASS MECHA
Y08
645 049 6271 SCR 2.6 X 10,CD MECHA
Y09
645 025 2433 FIBER WASHER,FOR CD MECHA
Y11
645 016 5078 SCREW,CD SW BD
Y12
645 049 6288 SCR 3 X 8,EJECT GEAR HOLDER
Y13
645 025 2426 SCREW 3X12,PWR TRANS
Y14
645 018 3690 SCREW,FOR AC SKT
Y15
645 049 6271 SCR 2.6 X 10,MAIN PCB
Y18
645 049 6295 SCR 3 X 25,BOTTOM CAB
Y19
645 025 2402 SCREW 2X8,CD MECHA BKT
Y20
645 036 2644 SCR 3X8,ANT
Y21
645 018 0521 SCREW,SPK NET
Y22
645 025 2372 SCREW 3X8,SPK BOX
Y23
645 026 6218 SCREW 3X20,SPK BOX
- 7 -
DESCRIPTION
(MX)(XE)(AU)(CA)(US)
(MX)(AU)(US)
DESCRIPTION
