TUNER ADJUSTMENTS

• Use a plastic screw driver for adjustments.
• Adjust the intermediate frequency of AM and FM to the frequency of ceramic filter.
• Set of unit
Supply voltage
: DC 12V
Speaker
: 8 ohms
Standard output
: 50 mW
Function switch
: RADIO
a.PARTS LOCATION
(1). AM IF ADJUSTMENT
AM LOOP ANT
0.1U
IC301
18PIN
(FIG.1)
(2). FM IF ADJUSTMENT
300PF
0.1U
(FIG.2)
BAND
STEP
MW-IF
1
450 KHz
10.5
BAND
STEP
10.7
FM-IF
1
10.9
WAVE FORM
(MHZ)
- 2 -
SING.
RADIO
ADJUST-
FRE.
SETTING
MENT
450KHz
T802
SING.
RADIO
ADJUST-
FRE.
SETTING
MENT
10.7MHz
- - - -
REMARKS
ADJUST FOR
BEST IF WAVE
FORM
REMARKS
- - - -
