Print Head - Canon PIXMA iP5300 Service Manual

Acoustic noise
Environmental
requirements
Power supply
External dimensions
Weight
Related standards
(Printer, Adapter)
Serial number location
Remaining ink amount
detection
Paper type detection
Print head alignment
<Print head>
Type

Print head

Ink color
Ink tank
Weight (Net)
Supply method
Part number
- Presence of CD / DVD
Highest print quality settings: Approx. 34.0dB (Photo Paper Pro, Custom 1, paper feeding from
the ASF)
During operation
Non operation
Power supply voltage, frequency
AC 100 to 240V, 50/60Hz
With the trays retracted: Approx. 444 (W) x 303 (D) x 160 (H)mm
Approx. 6.8kg, including print head and ink tanks
Electromagnetic radiance:
VCCI, FCC, IC, CE Mark, Taiwan EMC, C-Tick, CCC (EMC), Korea MIC, Gost-R
Electrical safety:
Electrical Appliance and Material Safety Law (DENAN), UL, C-UL, CB Report, CE Mark,
GS, Gost-R, FT, SASO, CCC, SPRING, Korea EK, IRAM (Argentine)
Environmental regulations:
RoHS (EU), WEEE (EU), Korea Package Recycle Law, Green Point (Germany), Energy
Star, Eco Mark, Law on Promoting Green Purchasing
On the carriage flexible cable holder (visible on the right of the carriage after the printer is
turned on, the top cover is opened, and the carriage moves to the center).
Available (detection by optical method and dot count, enabled at default)
Not available
Available (automatic or manual alignment via the printer driver Maintenance tab, or via the
printer button in Direct Printing, automatic alignment at default)
Single head with 5 removable ink tanks (each color)
Pigment-based BK:
512 nozzles, 600 dpi, 30 pl
Dye-based BK / Y:
512 nozzles each, 1,200 dpi, 5 pl
Dye-based C / M:
Three 512 nozzles for C and M respectively, 2,400 dpi, 5 pl / 2 pl / 1 pl
Pigment-based black
Dye-based black, cyan, magenta, yellow
PGI-5BK (pigment-based), CLI-8BK / C / M / Y (dye-based)
Print head, approx. 58.4g
As a service part (not including ink tanks)
QY6-0067
Temperature 5C to 35C (41F to 95F)
Humidity 10%RH to 90%RH (no condensation)
Temperature 0C to 40C (32F to 104F)
Humidity 5%RH to 95%RH (no condensation)
Power
consumption
Approx. 12W
(max.)
Standby Power-off
Approx. 1.0W Approx. 0.5W
