Table Of Contents - Canon PIXMA iP5300 Service Manual

PIXMA iP5300
II. TABLE OF CONTENTS
Part 1: MAINTENANCE
1. MAINTENANCE
1-1. Adjustment, Periodic Maintenance, Periodic Replacement Parts, and Replacement Consumables by
Service Engineer
1-2. Customer Maintenance
1-3. Product Life
1-4. Special Tools
1-5. Serial Number Location
2. LIST OF ERROR DISPLAY / INDICATION
2-1. Operator Call Errors
2-2. Service Call Errors
2-3. Warnings
2-4. Troubleshooting by Symptom
3. REPAIR
3-1. Notes on Service Part Replacement
3-2. Special Notes on Repair Servicing
3-3. Adjustment / Settings
(1) Paper feed motor adjustment
(2) Grease application
(3) Ink absorber counter setting
(4) User mode
(5) Service mode
3-4. Verification Items
(1) Service test print
(2) EEPROM information print
4. MACHINE TRANSPORTATION
Part 2: TECHNICAL REFERENCE
1. NEW TECHNOLOGIES
2. CLEANING MODE AND AMOUNT OF INK PURGED
2-1. Cleaning
2-2. Moisturizing Timer Sequence
3. PRINT MODE
4. FAQ (Problems Specific to the iP5300 and Corrective Actions)
Part 3: APPENDIX
1. BLOCK DIAGRAM
2. CONNECTOR LOCATION AND PIN LAYOUT
2-1. Logic Board
Service test print, EEPROM initialization, Ink absorber counter resetting
Destination setting
LF / Eject correction
Left margin correction
