Ink absorber counter reset
LF / Eject correction
Left margin correction
Destination settings
Note: At the end of the service mode, press the Power button. The paper lifting plate of the sheet feed unit will be
raised.
<Service mode operation procedures>
1) With the printer power turned off, while pressing the Resume/Cancel button, press and hold the Power button.
(DO NOT release the buttons). The Power LED lights in green to indicate that a function is selectable.
2) While holding the Power button, release the Resume/Cancel button. (DO NOT release the Power button.)
3) While holding the Power button, press the Resume/Cancel button 2 times, and then release both the Power and
Resume/Cancel buttons. (Each time the Resume/Cancel button is pressed, the Alarm and Power LEDs light
alternately, Alarm in orange and Power in green, starting with Alarm LED.)
4) When the Power LED lights in green, press the Resume/Cancel button the specified number of time(s)
according to the function listed in the table below. (Each time the Resume/Cancel button is pressed, the Alarm
and Power LEDs light alternately, Alarm in orange and Power in green, starting with Alarm LED.)
Time(s) LED indication
0 times Green (Power)
1 time Orange (Alarm)
2 times Green (Power)
3 times Orange (Alarm)
4 times Green (Power)
5 times Orange (Alarm)
6 times Green (Power)
7 times Orange (Alarm)
8 times Green (Power)
9 times Orange (Alarm)
See "Service mode operation
procedures" below.
See "Service mode operation
procedures" below.
See "Service mode operation
procedures" below.
See "Service mode operation
procedures" below.
Function
Power off
Service test print
EEPROM information
print
EEPROM initialization
Ink absorber counter
resetting
Destination settings
Print head deep cleaning
CD / DVD check pattern
print
CD / DVD print position
correction (horizontal: X
direction)
CD / DVD print position
correction (vertical: Y
- Ink absorber counter value (ink amount in
the ink absorber)
- CD / DVD correction value
- LF / Eject correction value
- Left margin correction value
- Record of disabling the function to detect the
remaining ink amount
If the ink absorber counter value is 7% or
more, replace the ink absorber kit.
Remarks
When the print head is not installed, the carriage
returns and locks in the home position capped.
See 3-4. Verification Items, (1) Service test print.
See 3-4. Verification Items, (2) EEPROM
information print.
Press the Resume/Cancel button the specified
number of time(s) according to the destination.
Cleaning of both Black and Color
Not used in servicing.
Not used in servicing.
Not used in servicing.
