www.lionelcorporation.com
616 Flying Yankee
Streamline Train Set
OPERATOR'S MANUAL
Traditional Version
Compatibility
This engine will operate on any
traditional O-31 Gauge track system,
including RealTrax® or ScaleTrax™ or
traditional tubular track. It is also
compatible with most standard AC
transformers. (See page 8 for a complete
list of compatible transformers and
wiring instructions.)
PLEASE READ BEFORE USE AND SAVE
Advertisement
Table of Contents
Related Manuals for Lionel 616 Flying Yankee
Summary of Contents for Lionel 616 Flying Yankee
- Page 1 616 Flying Yankee Streamline Train Set OPERATOR’S MANUAL Traditional Version Compatibility This engine will operate on any traditional O-31 Gauge track system, including RealTrax® or ScaleTrax™ or traditional tubular track. It is also compatible with most standard AC transformers. (See page 8 for a complete list of compatible transformers and wiring instructions.)
-
Page 2: Table Of Contents
Do not operate the hobby transformer with damaged cord, plug, switches, buttons or case. This product may be protected by one or more of the following patents: 6,019,289; 6,280,278; 6,281,606; 6,291,263; 6,457,681; 6,491,263; 6,604,641; 6,619,594; 6,624,537; 6,655,640. Rev: _Lionel LCCA 616 Flying Yankee[Traditional] 7/19/13 ©2013, M.T.H. Electric Trains®, Columbia, MD 21046... -
Page 3: Set Up Checklist
Assembling The Set 1. Place the engine and cars on straight, level track. 2. Press down on the button on top of the vestibule over the truck Figure 2: Step 2[Vestibule Button] Lionel Corporation LCCA 616 Flying Yankee O Gauge Streamline Train... - Page 4 At this point, you are ready to put your engine on the track and begin running it. Figure 5: Vestibule and Car Connected Lionel Corporation LCCA 616 Flying Yankee O Gauge Streamline Train...
-
Page 5: Basic Operation
The engine will maintain the speed you set after you release the throttle until you turn it again to change the voltage and speed. Lionel Corporation LCCA 616 Flying Yankee O Gauge Streamline Train... -
Page 6: Maintenance
The locomotive utilizes a direct drive motor that should not need direct lubrication. However, it will be necessary to grease the idler gears located on the inside of the drive wheels. Grease Idler Gears (G) Figure 8: Grease Idler Gears Lionel Corporation LCCA 616 Flying Yankee O Gauge Streamline Train... -
Page 7: Cleaning The Wheels And Track
Figure 9: Remove Mounting Screw 2. Remove the screw to allow the truck block to release from the body 3. Remove headlight mounting bracket screws and remove bracket 4. Replace burned out headlight Lionel Corporation LCCA 616 Flying Yankee O Gauge Streamline Train... - Page 8 5. Reassemble in reverse order; being careful not to pinch any wires. Replacement bulb harnesses are available directly from the M.T.H. Parts department. (Order online: www.mthtrains.com, e-mail: parts@mth-railking.com,Fax: 410-423- 0009, Phone: 410-381-2580, Mail: 7020 Columbia Gateway Drive, Columbia MD 21046-1532). Lionel Corporation LCCA 616 Flying Yankee O Gauge Streamline Train...
-
Page 9: Transformer Compatibility And Wiring Chart
Lionel TW 8-18v 175-Watt Standard Lionel ZW A,B,C or D 8-20v 275-Watt Standard Lionel Post-War A,B,C or D Common 0-20v 135/190 Watt Electronic Celebration Series ZW * Conventional Mode Only Lionel Corporation LCCA 616 Flying Yankee O Gauge Streamline Train... -
Page 10: Service & Warranty Information
M.T.H. website in order to obtain warranty service. Lionel Corporation Tinplate products manufactured within five years from the date of purchase are warrantied for one year against defects in material or workmanship, excluding wear items such as light bulbs, pick-up rollers, batteries, smoke unit wicks, and traction tires.
