Lionel 6-16706 Assembly And Operating Instructions

Animated "o" gauge box car

ASSEMBLY AND OPERATING INSTRUCTIONS

ANIMATED "O" GAUGE BOX CAR

The figure included with this car is packed separately in the box and must be inserted onto the balance shaft. First remove the

box car from the frame by slightly pulling the sides away in the middle of the boxcar in the area of the doors, from the frame

and lifting the body straight up. (See Figure 1). Next , support the weighted side of the beam with your finger and press the fig-

ure onto the tab as shown in Figure 2. The Figure is made from a soft material that easily presses on the beam. Replace the

body making sure that the opening on the roof is on the same side as the figure.

NOTE: The Figure supplied

with this set may differ from

the one shown.

FIGURE 1

BALANCE BEAM

(WEIGHTED SIDE)

FIGURE 2

71-6706-250
