Speaker installation example

Speaker installation example
Installation on a floor or shelf
Ceiling installation
Wall mounting
･ Adjust the speaker angle. ➡Refer to P.22.
･ Example of installation to a ceiling or wall. ➡ Refer to P.25.
･ Install the speaker to the ceiling or wall. ➡Refer to P.26 - 30.
･ Adjust the speaker angle. ➡Refer to P.22.
･ Example of installation to a ceiling or wall. ➡ Refer to P.25.
･ Install the speaker to the ceiling or wall. ➡Refer to P.26 - 30.
･ Adjust the speaker angle. ➡Refer to P.22.
