- Preparation for installation -
Screwdriver
①
Speaker
Speaker base
cover
Hexagon
head screw
Screws x3
Speaker base
①
Speaker
Speaker base
④
Allen key (small)
Speaker base
cover safety
cable
1
Remove the screws from the bottom of the speaker
base.
Tip
The screws which are removed will not be used.
Retain these screws in case they are required in the
future.
2
Remove the speaker base cover.
3
Remove the hexagon head screw which is used for
securing the speaker base cover safety cable from
the speaker base.
Tip
The hexagonal head bolt which is removed will be
used later, so be careful not to lose it.
