Preparations for Operation

Lay a soft cloth or the like beneath the purifi er to protect the fl oor against scratch.
Note
No cleaning effect is obtainable if the fi lter is installed with plastic bag. It may also be a cause of malfunction.
Setting Filter in Purifier
Remove the panel.
Lay the air purifier unit with the
front upward on a stable and
horizontal surface.
Put your fingers under the panel
(two locations), lift the panel
slowly and slide it slightly to the
top side to remove.
Hold the prefilter by the
lugs to remove.
Note Do not open the panel forcibly. Parts may break.
Reinstall the panel on the unit.
Insert the four tabs of the prefilter securely into
the holes on the unit.
Install the filter so that the marking " 手前側 " on the
filter side face will face the panel.
Insert the two tabs on the inside of the panel
upper side securely into the two cylindrical
notches on the top of the unit.
Insert one tab into a cylindrical notch and then do
the other tab in the same manner.
Gently push bottom of the panel until it clicks to
close it securely.

Inserting Batteries into Remote Controller

Remove the battery
compartment cover.

Installation

Avoid any place close to heating appliance, and select a well-ventilated place.
Do not place the purifi er on unstable pedestals or the like.
Note
Falling or dropping of the purifi er may cause damage
or failure.
(Perform the same procedure when replacing filter.)
Lugs
Insert batteries and close the cover.
Insert the provided two "AAA" R03 batteries
with the correct polarities as instructed.
Cover
Since the batteries are provided when shipped
from the factory, their lives may be shorter than
brand-new ones because of self-discharge.
Batteries are consumable
When replacing batteries, replace the two batteries simultaneously.
Only use two manganese batteries or two alkali batteries. Do not mix them.
Install the filter.
Take the filter out
of the plastic bag
and install it in the
unit.
Install the filter so that
the arrow " ↓ FRONT"
on the filter side face
faces the panel.
Tabs (4 locations)
Holes
Tabs
Cylindrical notches
Face the white
surface of the
filter to your side.
Indication
−
＋
＋
−
E-7
