  • Page 1 USER MANUAL O-RING...

  • Page 3: Table Of Contents

    Minimum distance from flammable materials INSTALLATION DATE PrelImInary oPeratIonS REFERENCE SERVICE Wiring How to load the pellets PHONE NUMBER o-rInG deScrIPtIon hoW to uSe the o-rInG OFF state IntroductIon Switch on Work phase Safety InformatIon The grate Turning off General InformatIon...
  • Page 4 alarmS (reference table) maIntenance Cleaning should be provided by the user Clean the surfaces Grate cleaning should be carried out before each switch-on Cleaning the ash pan Cleaning glass Warranty Warranty Certificate Warranty conditions Info and problems WIrInG dIaGram...

  • Page 5: Introduction

    The children nance Manual, the company Ravelli srl wishes to provide the user with all the should be supervised to make sure they do not play with the device.

  • Page 6: Safety Information

    • European regulations. By handing over to the end user this manual, Ravelli srl denies all liability, both • The stove must only be powered using high quality pellets with a diameter of civil and criminal, for accidents arising from non-compliance with instructions 6 mm as described in the dedicated chapter.

  • Page 7: General Information

    They must always be protected from the damp both during transport and in storage. Ravelli srl recommends a pellet with a diameter equal to 6 mm. If you wish to use a pellet type with a different diameter contact the support centre to carry out the due regulations on the stove.

  • Page 8: How Is A Stove Made

    how is a stove made? combustion Combustion is nothing more than a chemical reaction in which two agents, called the fuel and the oxidizing agent, combine to produce a new substance. A considerable amount of heat is also produced from this reaction (concept of pellet stove functioning).

  • Page 9: Stove Installation

    • requirements met (followed by the compilation of fume dataplate to be affixed technical standards and directives to the same). All Ravelli srl products are manufactured according to the directives: 89/106 CEE approved installations • construction materials...

  • Page 10: System Compatibility Check

    rooms (only watertight installation) or studios (unless installed in a hermetically ance with the regulations issued by the standardization bodies and should be sealed combustion chamber). installed according to state-of-the-art standards. EXCERPT OF STANDARD UNI/EN 1443 air vent It is used to fuel the fire box and input air into the room; it should be fitted di- System compatibility check rectly from the outside (not through other rooms, garage etc.;...

  • Page 11: Flue Dataplate

    2) DIAMETER 3) DISTANCE FROM FLAMMABLE MATERIAL: Section compiled by the installer 4) INSTALLER (name/address) Mario Bianchi Via Rossi 24 Calcinate (BG) 27/01/2014 5) DATE: WARNING: THIS LABEL SHOULD NOT BE REMOVED OR MODIFIED Internal chimney section USER MANUAL O-RING...
  • Page 12 Safe distances for proper installation of chimney terminal: 90° Clearance area Symbol Description [mm] Side distance from dormer window 1500 Dormer Height above the ridge of dormer window frame 1000 Clearance area window(2) Symbol Description [mm] Front distance from dormer window 3000 Distance from top or side line of openings or windows 1000...

  • Page 13: Testing And Commissioning

    Boilers 1 year 1 year The test is considered successfull when all operation phases are com- Fume exhaust system 4t of fuel used 4t of fuel used pleted without encountering anomalies. USER MANUAL O-RING...
  • Page 14 declaratIon of conformIty of the State-of-the-art SyStem As per para.I of Art. 7 of Ministerial Decree 37 of January 22, 2008 no. 20 Commissioned by The undersigned installed at the premises in the municipality of prov. ( owner or legal representative of the company street floor internal,...
  • Page 15 £ installed parts and materials suitable for the place of installation (Art.5 and 6) verification and chimney seal test £ inspected the system for safety purposes and the functionality with positive out- DECLINE come, having carried out the checks required by the standards and the provisions all liability for injuries or damages to property arising from tampering with the of the law.
  • Page 16 Reference key of system declaration of conformity execution of the installation in all its phases in compliance with all technical standards provided by the manufacturer of the system or the product. Like in the case of gas plants, by “other” we may mean the replacement of a device installed in Example: any certificates containing the outcome of the checks performed on the system before a fixed manner.

  • Page 17: Examples Of Installation Of A Pellet Stove

    T joint for condensate T-fitting Insulated flue Ash collected in 90° bend Grill that enables air pas- sage into the skylight well with opening for inspecting the chimney Combustion ashes collection chamber+ condensate drain cock fig.1 fig.3 fig.2 USER MANUAL O-RING...
  • Page 18 This type of installation (see fig. 4) requires insulated chimney since the entire This type of installation (See fig. 5) does not require an insulatd flue duct be- smoke duct was assembled inside the house. The lower part of the flue has an cause the latter is installed inside the building and a part of it is located inside assembled “T”...

  • Page 19: Examples Of Installation Of A Pellet Insert

    Protection from rain Protection from rain T fitting with collection and condensate chamber Pipe Inspection door Exploded view of T fitting T fitting with inspection ash collector cap fig.6 fig.7 USER MANUAL O-RING...

  • Page 20: Technical Data Sheet

    Smoke temperature °C 188.8 196.3 Hourly consumption of pellets kg/h min 1.65 2.33 fig.8 The data shown above are indicative and not binding. Ravelli reserves the right to make any modifications for the purpose of improving the performances of the product.

  • Page 21: Preliminary Operations

    In the following pages we shall see how to use the device to that the door and the ash drawer are properly close. control the Ravelli Young pellet stove. The O-Ring interacts with the user by means of 4 sets of 6 LEDs each. The latter propose animations in intense BLUE how to load the pellets or RED light, depending on the phase or the situation.

  • Page 22: How To Use The O-Ring

    I. The O-Ring will display a BLUE blinking light through the first LED on top right, as shown in the figure:...

  • Page 23: First Infeed Screw Loading

    120 sec. >> 24 LEDs lit extra fan blow Due to its innovative O-ring, the Ravelli Young stove allows the user to vary the blow of room fan for each of the 12 powers of the stove. This feature is par-...

  • Page 24: Installation And Activation Of External Thermostat

    It is only added the MODULATION function. Chronothermostat and Eco-Stop are disabled. It will not be possible to switch off the stove from the external thermo- stat. It will run continuously in modulation mode. Below is shown the way in which the O-Ring indicates this mode: -10 VOLT +10 VOLT...

  • Page 25: Warning Sign - Hot Fume

    LEDs, and simultaneously blocks all functions - except fro stove switch-off enter the alarm 1 BLACK OUT state and on the O-Ring will be displayed the fol- function;...

  • Page 26: Alarm 3 - Fume Overheating (Hot Fume)

    The thermostat blocks the pellet infeed screw and the electronic board detects the error and blocks the stove; the error is displayed on the O-Ring with 2 red If the heater does not produce a flame within a specified number of minutes and leds in this position.

  • Page 27: Alarm 8 - No Depressurization

    The gear motor is not loading pellets. jects inside that may prevent the proper AL 06 operation of the auger. PELLETS FINISHED Regulate pellets setting from “SET AIR/ Not enough pellets loaded. PELLETS”. If the problem persists, Contact the Sup- port Service. USER MANUAL O-RING...

  • Page 28: Maintenance

    that the brazier is clean and so that they are always excellent combustion, thus The manual reset thermostat connected to Reset the thermostat by pressing the the hopper. button on the back of the stove. avoiding any overheating that may cause changes in the color of the paint or AL 07 Switch off the stove, clean the brazier and peeling of the door coating.

  • Page 29: Cleaning The Ash Pan

    • Electrical-mechanical DO NOT SWITCH ON THE STOVE IF YOU NOTICE ANY DAMAGES ON parts* GLASS SURFACE. CONTACT THE TECHNICAL SUPPORT SERVICE TO HAVE IT REPLACED. * Operations to be carried out by authorized technical staff. USER MANUAL O-RING...

  • Page 30: Warranty

    Warranty certificate centre as they are authorized to provide solutions to all requests and intervene Ravelli srl would like to thank you for agreeing to buy one of our pellet stoves directly, when necessary. and invites you, the customer, to: •...

  • Page 31: Wiring Diagram

    HEAT EXCH. FAN FUME ENCODER NEUTRAL NEUTRO SCAMBIATORE 230VAC POWER FUMI ALIMENTAZIONE SUPPLY UNIT 230VAC VENT. FI FUME FUN DEP=VACUUM METER TSP=PELLET TANK SAFETY THERMOSTAT * to ensure proper operation please observe the polarity of the thermocouple USER MANUAL O-RING...
  • Page 32 note...
  • Page 33 USER MANUAL O-RING...
  • Page 34 note...
  • Page 36 Kupfer, 31 - 25036 Palazzolo sull’Oglio / BS - ITALY Tel. +39.030.7402939 Fax. +39.030.7301758 Internet: www.ravelligroup.it E-mail: info@ravelligroup.it Ravelli does not assume any responsibility for any errors in this booklet and considers itself free to make any variations to the features of its products without notice.
