- Page 1 Brochure for Francesca model...
- Page 2 Brochure for Francesca model Preparing the stove: installation with side discharge Remove the micro-connections shown in the illustration After removing the left side panel (see Remove the side panel, and then the points 1 to 5 in section “Access to “T“...
-
Page 3: Combustion Chamber
Brochure for Francesca model Maintenance and cleaning: Before carrying out any maintenance operation take the following precautions: - Make sure that the general power switch has been disconnected. - Make sure that all the parts of the stove are cold. - Page 4 Brochure for Francesca model Cleaning the ashes drawer: The ashes drawer must be cleaned every 2 days, depending on the length of time the stove is used and the type of pellet used. To access the drawer, open the door (see figure 1) and extract the ashes drawer (see figure 2).
- Page 5 Brochure for Francesca model Cleaning the suction duct (every 1000 hours): The suction duct must be cleaned once every 3 months (the time may vary depending on the quality of the pellet used). Follow the opera- tions illustrated in the images below to access the inspection hatches.
- Page 6 Brochure for Francesca model Remove the screws that attach the side panels to the top of the stove Remove the side panel.
- Page 7 Brochure for Francesca model SCRAPER GASKET INSPECTION HATCH (2 ON THE RIGHT SIDE) INSPECTION HATCH (1 ON THE LEFT SIDE) GASKET GASKET PARTS / FREQUENCY 1 DAY 2-3 DAYS 30 DAYS 60-90 DAYS 1 SEASON Fire pot Ashes drawer Glass...
-
Page 8: Technical Diagram
Brochure for Francesca model TECHNICAL DIAGRAM... - Page 11 Brochure for Francesca model Aico SpA Via Kupfer, 31 - 25036 Palazzolo sull’Oglio / BS - ITALY Tel. +39.030.7402939 Fax. +39.030.7301758 Internet : www.ecoteck.it E-mail : info@ecoteck.it Aico SpA does not assume any responsibility for any errors in this booklet and...
