Three-colour indicator light
The indicator light on your terminal enables you to monitor the system. The light has five possible
statuses (colours and/or flashing):
Flashing green: message received (voice or screen) or call received in the " calls received "
memory.
Orange fixed: indicates traffic overload level 1 (1 is calls on hold).
Flashing orange: terminal on test.
Red fixed: indicates traffic overload level 2 (call unanswered within 20 seconds or number of calls
on hold exceeds number of operator stations).
Flashing red: several low priority system messages present or one very serious system message
indicating a system hardware fault.
Programmable keys and icons
To make a call, activate a service or manage your calls.
Icons are associated with each of these keys:
Line icons :
Incoming call (flashing).
Call in progress.
Call on hold.
Call on common hold.
Preprogrammed function keys:
Internal or outside line key.
Lines 1 to 15: Outside line key on your system.
Trunk 1
Divert your calls to another terminal.
Access the various mail services.
Access your personal directory.
Group supervision.
Normal or restricted mode.
Make an ISDN call.
Transfer call to another terminal.
Some other keys can be programmed by your installation technician as a func-
tion of your requirements:
Key which must be programmed by your installation technician to access a service.
Function icons :
Function active.
Function requiring action.
Terminal or line busy.
