  • Page 1 Sprinter 150/150M/250M User Manual Sprinter_01 Version 1.0 EN, DE, FR, ES, IT, PT, NL, NO, SV, FI, DA...

  • Page 2: Introduction

    Enter the model and serial number in your manual and always refer Indicates a potentially hazardous situation or an unintended to this information when you need to contact your agency or Leica use which, if not avoided, could result in death or serious injury.

  • Page 3: Table Of Contents

    14. International Warranty, Software d) Gunsight j) Levelling foot- Licence Agreement ............32 e) Focusing knob screw 15. Index ................33 Container Contents Sprinter, batteries (4x), allen key, user manual, strap, CD-ROM* (incl. DataLoader), USB cable*. Sprinter 150/150M/250M - 1.0.0en Instrument Components...

  • Page 4: Measurement Preparations

    Eyepiece Adjustment Point the telescope to a uniform light surface such as a wall or a piece of paper. Turn the eyepiece until the cross hairs are sharp or distinct. Sprinter 150/150M/250M - 1.0.0en Measurement Preparations...

  • Page 5: User Interface

    Press and hold for 3 seconds to start and stop tracking measurement / timer measurement* c) Height / Alternating between Height and Cursor up (in Menu / Settings mode), Switch between intermediate sight Distance display I and foresight F in line leveling program BIF* Distance Sprinter 150/150M/250M - 1.0.0en User Interface...
  • Page 6 BF line levelling * MEAS MENU BFFB line levelling * MENU BFFB BFFB BFFB BFFB BFFB Adjustment Mode BIF line levelling * Tracking Cut & Fill * Settings Height Difference Measurement interval / timer acti- vated * Sprinter 150/150M/250M - 1.0.0en User Interface...
  • Page 7 Measured distance Height Difference Mean height difference in BFFB * Elv: Elevation Fill / raise height to reach design elevation * D.Elv: Design Elevation * Cut / lower height to reach design elevation * Sprinter 150/150M/250M - 1.0.0en User Interface...
  • Page 8 Measurement recorded to external device in GSI-8 format via RS232 cable. 8. Adjustment Adjustment program. 9. Inverse Staff ON [Inverted], OFF [Upright], AUTO Recognition mode setting of staff orientation. [Auto recognition of staff orientation] Sprinter 150/150M/250M - 1.0.0en User Interface...
  • Page 9 Timer* Input measurement time interval 00 hr: 00 min (applicable to Ht / Dist application only). Press height / distance or dH or backlight or menu key. A message "stop Tracking" will be displayed. Sprinter 150/150M/250M - 1.0.0en User Interface...

  • Page 10: Set Of Characters

    ENTER key to clear the entire last input value. Step Description To discard entry Press to switch on the instrument, Leica logo Press ESC key to discard entry and restore old value. is displayed follow by the default measure- Point ID increment ment standby mode.
  • Page 11 Measurement to measure to target progress target displayed The following results are displayed accord- ingly;- target reduced level (RL), target height difference (dH) with respect to the reference staff, height and distance of target point. Sprinter 150/150M/250M - 1.0.0en Operation...
  • Page 12 The following results are displayed accord- ingly- target reduced level (RL) / Elevation, height of target point and cut / fill value at target point with respect to the Design reduced level / Design Elevation. Sprinter 150/150M/250M - 1.0.0en Operation...
  • Page 13 Go to menu set "Interme- Foresight measurement Measure to backsight of diate sight with prompt diate Sight" to OFF OR displayed with prompt next change point with message press Height & Distance message prompt message key, measure to foresight Sprinter 150/150M/250M - 1.0.0en Operation...
  • Page 14 Height & Distance key, then change point. measure to the foresight staff. Foresight measurement displayed. System refreshes a standby display for measurement to the backsight of next change point. Sprinter 150/150M/250M - 1.0.0en Operation...
  • Page 15 Timer icon will be shown at the top left Foresight (second sighting) measure- of LCD display to indicate current measurement mode. To stop ment displayed. timer measurement, press and hold measuring key for 3 seconds. Measure to the backsight staff (second sighting). Sprinter 150/150M/250M - 1.0.0en Operation...

  • Page 16: Data Transfer Dataloader

    3. Power On the instrument, wait for the double beeps and USB icon will be shown on the LCD of the instrument. 4. Start the DataLoader from default C: \ Program files \ Leica- Geosystems. 5. Left click on 'USB Connect' button in the DataLoader and all info relevant to instrument will be displayed.

  • Page 17: Check & Adjust

    ENTER key to accept. adjustment result. Now shift the Sprinter towards staff A and set it up at about 3 m to Optical collimation error can be corrected by adjusting the staff A. reticle. Sprinter 150/150M/250M - 1.0.0en Check & Adjust...
  • Page 18 Center bubble if it extends beyond the centering circle. mation needs to be adjusted. Correct half of the error with the Allen key. Repeat steps 1 to 4 until the circular level bubble is centered at any random telescope pointing. Sprinter 150/150M/250M - 1.0.0en Check & Adjust...

  • Page 19: Error Messages

    Move staff or instrument closer together. E112 Too Cold ! Stop working, external temperature is outside the instrument operating temperature. E113 Too Hot ! Stop working, external temperature is outside the instrument operating temperature. Sprinter 150/150M/250M - 1.0.0en Error Messages...

  • Page 20: Operation Messages

    Press measure key for 3 seconds to restart tracking mode. Tracking will hold after 10 unsuccessful meas- urements. Abort Measurement! Current measuring process is terminated. Downloading Data! Downloading of data from the internal memory to an external device is in progress. Sprinter 150/150M/250M - 1.0.0en Operation Messages...
  • Page 21 Pressing ENTER key to quit application; otherwise, press ESC key to return to current application. Quit This Application? Prompt message to quit current application, pressing ENTER key to quit application; otherwise, press ESC key to return to current application. Sprinter 150/150M/250M - 1.0.0en Operation Messages...

  • Page 22: Care And Transport

    When transporting the product by rail, air or sea, always use the • Use only a clean, soft, lint-free cloth for cleaning. If necessary, complete original Leica Geosystems packaging, transport container moisten the cloth with water or pure alcohol. and cardboard box, or its equivalent, to protect against shock and Do not use other liquids;...

  • Page 23: Safety Directions

    Leica Geosystems AG, CH-9435 Heerbrugg, hereinafter referred to • Modification or conversion of the product. as Leica Geosystems, is responsible for supplying the product, • Use after misappropriation. including the user manual and original accessories, in a completely •...

  • Page 24: Hazards Of Use

    • To inform Leica Geosystems immediately if the product and the DANGER application becomes unsafe. Because of the risk of electrocution, it is very dangerous to...
  • Page 25 Adhere to the instructions given by the computer manufacturer with Be careful when pointing the product towards the sun, regard to field use in conjunction with Leica Geosystems products. because the telescope functions as a magnifying glass and can injure your eyes and/or cause damage inside the product.
  • Page 26 WARNING Precautions: High mechanical stress, high ambient temperatures or Do not open the product. Only Leica Geosystems authorized immersion into fluids can cause leackage, fire or explosions of the service workshops are entitled to repair these products. batteries.
  • Page 27 Although the product meets the strict regulations and standards and rendering the environment liable to contamination. which are in force in this respect, Leica Geosystems cannot Precautions: completely exclude the possibility that other equipment may be The product must not be disposed with household disturbed.
  • Page 28 Although the product meets the strict regulations and standards However, there is no guarantee that interference will not occur in a which are in force in this respect, Leica Geosystems cannot particular installation. completely exclude the possibility that the product may be disturbed...
  • Page 29 Labelling Sprinter 150/150M/250M - 1.0.0en Safety Directions...

  • Page 30: Technical Data

    • Electronic measurement with Sprinter aluminum barcode staff: • 1.0 mm (Sprinter 250M) • 1.5 mm (Sprinter 150/150M) • Optical measurement with standard aluminum E-scale/Numeral staff: 2.5 mm • Standard Deviation for single staff reading: 0.6 mm (electronic) and 1.2 mm (optical) at 30m Distance Accuracy 10 mm for D<= 10 m...
  • Page 31 Internal Memory Storage* Capacity: up to 1000 points. Data Transfer* Program: To DataLoader via USB, to Leica Geo Office and HyperTerminal via RS232 on PC, using a Windows® application Power Supply • Sprinter 150: internal battery • Sprinter 150M/250M: internal battery and external via RS232 port.
  • Page 32 • Width (from the external face of focusing drive to the external side of circular bubble holder) 196 mm • Height (incl. hand grip, base fully extended) 178 mm Container: • Length 400 mm • Width 220 mm • Height 325 mm Weight 2.55 kg (including 4 AA batteries) Sprinter 150/150M/250M - 1.0.0en Technical Data...

  • Page 33: International Warranty, Software Licence Agreement

    Leica Geosystems. Such software is protected by copyright and AutoOff ..................8 other laws and its use is defined and regulated by the Leica Averaging ................. 8 Geosystems Software Licence Agreement, which covers aspects...

  • Page 34: Index

    DataLoader ................15 Design Elevation (D.Elv) ............9 Language ................. 8 dH .................... 5 LCD display ................2 Levelling footscrew ..............2 Electronic Collimation Adjustment .......... 16 Error Messages ..............18 MEAS ..................4 Eyepiece .................. 2 Sprinter 150/150M/250M - 1.0.0en Index...
  • Page 35 Point ID increment ..............9 Timer Measurement ............... 14 Power ON ................3 Transport ................21 Program ................... 7 Unit ................... 8 Recording ................. 7 User Interface ................4 Reticle Adjustment ..............17 Rounding .................. 8 RS232 ..................8 Sprinter 150/150M/250M - 1.0.0en Index...
