Page 1: User Manual
Sprinter 50 User Manual Sprinter_01 Version 1.0 EN, DE, FR, ES, IT, PT, NL, NO, SV, FI, DA... - Page 3 User Manual Gebrauchsanweisung Manuel d'utilisation Manual del usuario Manuale d'uso Manual de Operação Gebruiksaanwijzing Brukerhåndbok Handbok Käyttäjän käsikirja Brugervejledning...
-
Page 4: Introduction
User Manual (English) Validity of this manual 1. Introduction This manual is valid for Sprinter 50. Purchase Trademarks Congratulations on the purchase of a new Leica All trademarks are the property of their respective Geosystems electronic level. It is designed to make owners. -
Page 5: Table Of Contents
/ or appreciable mate- 11. Technical Data ..........21 rial, financial and environmental damage. Important paragraphs which must be adhered to in practice as they enable the product to be used in a technically correct and efficient manner. Sprinter 50 - 1.0.0en Introduction... -
Page 6: Instrument Components
Focusing knob • Use the three levelling foot screws to center the Container Contents circular bubble in order to level the instrument. Sprinter, batteries (4x), allen key, user manual, error and operation messages leaflet, strap. Instrument Components Sprinter 50 - 1.0.0en... - Page 7 • Before starting work, let the instrument adjust to the ambient temperature (approx. 2 minutes per °C of temperature difference). • Avoid measuring through window panes. • Staff sections have to be fully extended and prop- erly secured. Sprinter 50 - 1.0.0en Measurement Preparations...
-
Page 8: User Interface
Power On or Off switch NONE b) MEAS Measuring trigger key / single Press and hold for 3 seconds to start Adjustment press to decline adjustment program / to accept measurement and adjustment result result User Interface Sprinter 50 - 1.0.0en... -
Page 9: Operation
Always aim at the center of bar code staff and focus the staff image for accurate measurement. Step Description Press to switch on the instru- ment, Leica logo is displayed follow by the default measure- ment standby mode. Aim at staff and focus. Lightly trigger the measurement key to activate measurement. -
Page 10: Check & Adjust
3 seconds to accept; otherwise single press of ment display, press and hold measuring key for 3 measuring key to decline adjustment result. seconds to accept. Optical collimation error can be corrected by adjusting the reticle. Check & Adjust Sprinter 50 - 1.0.0en... - Page 11 Correct half of the error with the Allen key. Repeat steps 1 to 4 until the circular level bubble is centered at any random telescope pointing. Sprinter 50 - 1.0.0en Check & Adjust...
-
Page 12: Error Messages
E114 Invalid Measurement ! Make another measurement. If further measurement proved to be futile, check staff position and Inverse Staff setting, check the lighting condition at the staff and stray light, check focusing and targeting, check if sufficient length of barcode in the field of view. Error Messages Sprinter 50 - 1.0.0en... -
Page 13: Operation Messages
Abort Measurement! Current measuring process is terminated. Wait! File System Clean Up! Cleaning up of temporary files/system files. Shut Down! System is switching OFF. Sand Clock Icon Please wait! System task is in progress. Sprinter 50 - 1.0.0en Operation Messages... -
Page 14: Care And Transport
When transporting the product by rail, air or sea, avoid the danger of leakage. always use the complete original Leica Geosystems packaging, transport container and cardboard box, or its equivalent, to protect against shock and vibration. -
Page 15: Cleaning And Drying
Description • Use with accessories from other manufacturers The following directions should enable the person without the prior explicit approval of Leica Geosys- responsible for the product, and the person who actu- tems. ally uses the equipment, to anticipate and avoid oper- •... -
Page 16: Limits Of Use
• To inform Leica Geosystems immediately if the similar situations by the person in charge of the product and the application becomes unsafe. -
Page 17: Software Licence Agreement
Such agreement is provided together with all products sible for the product. and can also be found at the Leica Geosystems home page at http://www.leica-geosystems.com/swlicense or your Leica Geosystems dealer. Sprinter 50 - 1.0.0en... - Page 18 Precautions: The person responsible for the product must make all users fully aware of the existing dangers. Safety Directions Sprinter 50 - 1.0.0en...
- Page 19 When setting-up the product, make sure that the actions may cause you to receive an electric shock. accessories are correctly adapted, fitted, secured, and locked in position. • Touching live components Avoid subjecting the product to mechanical stress. Sprinter 50 - 1.0.0en Safety Directions...
- Page 20 Before shipping the product or disposing of it, Precautions: discharge the batteries by running the product until Do not open the product. Only Leica Geosystems they are flat. authorized service workshops are entitled to repair When transporting or shipping batteries, the person in these products.
- Page 21 Dispose of the product appropriately in Although the product meets the strict regulations and accordance with the national regulations in standards which are in force in this respect, Leica force in your country. Geosystems cannot completely exclude the possi- Always prevent access to the product by bility that other equipment may be disturbed.
- Page 22 Although the product meets the strict regulations and WARNING standards which are in force in this respect, Leica This equipment has been tested and found to Geosystems cannot completely exclude the possi- comply with the limits for a Class B digital device, bility that the product may be disturbed by very pursuant to part 15 of the FCC rules.
- Page 23 • Consult the dealer or an experienced radio/TV technician for help. WARNING Changes or modifications not expressly approved by Leica Geosystems for compliance could void the user's authority to operate the equipment. Sprinter 50 - 1.0.0en Safety Directions...
-
Page 24: Technical Data
• Compensator range (Mechanically): ± 10' • Setting accuracy: 0.8" max. (Standard Deviation) • Magnetic field sensitivity: < 10" (Line-of-sight difference in horizontal constant magnetic field at a field strength of up 5 Gauss) Power Supply Internal battery Technical Data Sprinter 50 - 1.0.0en... - Page 25 • Protection against water, dust and sand: IP55 (IEC 60529) cations • Protection against Humidity: Up to 95% humidity no condensation. The effects of condensation are to be effectively counteracted by periodically drying out the product. Sprinter 50 - 1.0.0en Technical Data...
- Page 26 196 mm • Height (incl. hand grip, base fully extended) 178 mm Container: • Length 400 mm • Width 220 mm • Height 325 mm Weight 2.55 kg (including 4 AA batteries) Technical Data Sprinter 50 - 1.0.0en...
