FeiYu Tech G3 Steadycam Installation Instructions page 2

G3 Steadycam Installation Instructions
G3云台手持件安装说明书
45°
地平面
Horizon
横滚轴与地平面夹角不可超过45°
The angel between the roll motor and the vertical of the
ground should be less than 45°
- 1 -
更多相关信息可访问飞宇科技官方网站：www.feiyu-tech.com
Please visit the official website of Feiyu-tech to get related
information : www.feiyu-tech.com
45°
请先安装好Gopro3相机后，再通电。
Attention!
Please install the Gopro3 cameral
firstly ,then supply power.
Tech Specification：
TECH SPEC
Working Voltage
Static attitude
tracking accuracy
Motion attitude
tracking accuracy
Overload
protection
Overload
protection time
Max-torque
response time
Controlled pitch
angle accuracy
Controlled Roll
Angle Accuracy
Pitching Angle
control rate
Weight
按Down
Push Down
可以通过按钮
（UP,DOWN)来调
整俯仰角。
You can adjust the
pitch angle by the
button （UP,DOWN)
- 2 -
特性参数：
项目 最小 标准
7.0V 12.0V
工作电压
静止姿态跟踪精度 ±0.01°
±0.1° ±0.02°
运动姿态跟踪精度
电机过载电流保护
电机过载保护时间
电机输出最大力矩
响应时间
俯仰角可转动角度
- 90° 0°
横滚角度可转动角度
- 45° 0°
俯仰角控制速率
重量
Min-working Standard working
voltage
voltage
7.0V 12.0V
±0.01°
±0.1°
±0.2°
- 90°
0°
0°
- 45°
10°/S
128g
90°
按Up
Push Up
UP&DOWN按钮同时按
下1S时间，可以关闭电机控
制输出，再次同时按下1S时
可以恢复电机控制。
Buttons for open and close
control: by press buttons
"UP" and "DOWN" at
the same time for 1 second,
you can realize turn on or
off the Gimbal.
- 3 -
备注
最大
17.0V 2S~4S LIPO
±0.04°
±0.5°
0.8A
600s
电机过载600s后自动停止工
作
330us
+ 35°
+ 45°
10°/S
手柄重量
128g
Max-working
Remark
voltage
17.0V 2S~4S LIPO
±0.04°
±0.5°
0.8A
600s After overloaded 600s,
Gimbal will stop working
automatically.
330us
+ 45°
+ 45°
Handle weight
