SebArt
Mini Avanti
professional line
1.4m ARF Jet for EDF or P20 micro-turbine
Instruction Manual
The all new Mini Avanti Jet 1.4m ARF was designed by Italian champion aerobatic pilot Sebastiano
Silvestri. This sport ARF jet-model design is based on the Hawk full size aircraft design and modified
by adding the ultimate aerodynamic ideas of modern pattern models and using Seba's 15 years
experience in flying jets.... the result is surprising! This innovative design combined with the
lightweight structure, the fiberglass fuselage and all wood airframe wings and stabs, give the Mini
Avanti Jet 1.4m ARF an impressive precision and smoothness at any airspeed and flight condition.
Thanks to this low wing loading and the powerful 90mm 12 blades EDF or the P20 micro-turbine, it
can be a fantastic aerobatic jet-trainer... you will be amazed with your new Mini Avanti Jet ARF !
.....the only aerobatic limit to unlimited fun is your imagination!
Specifications:
Wing span: 1360 mm
Length: 1420 mm
Wing area: 38 sq. dm.
Radio: Minimum 6 channel
Weight with recommended power set up:
EDF: Weight (less battery): 2,900g Weight RTF (with 5800-6S): 3,800g 90mm 12 blades aluminium
EDF unit, 1750 Kw motor, 130A ESC with 8A BEC 5V
Micro-turbine P20: Weight (empty, less RX and Turbine battery): 3,050g Weight RTF (with 800-2S RX
batt. and turbine batt. + 650cc tank full): 3,700g
Conversion turbine set (including tank, thrust tube and other accessories) is available as an option
(item # A140-17)
Required radio system: • Minimum 6-channel radio system (better 9ch) • 7 micro servos 17gm for
elevators, ailerons, flaps and rudder • 3 servos for doors and steering , the door sequencer and the
electric retracts are factory installed • full extension set are available in the optional servo set (item
# A140-12 set)
Recommended Li-Po battery pack for best performance with EDF: • 5000-6S or 5800-6S Minimum 20
C-rate
Additional required tools: • Drill • Drill bits: 1,5mm • Phillips screwdriver • Hobby knife • Sanding
paper • Masking tape • Soldering iron
Additional required adhesives: • thin CA • medium CA • epoxy 5minutes • epoxy 20 minutes •
silicon
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sebart Mini Avanti
Summary of Contents for Sebart Mini Avanti
-
Page 1: Instruction Manual
Thanks to this low wing loading and the powerful 90mm 12 blades EDF or the P20 micro-turbine, it can be a fantastic aerobatic jet-trainer… you will be amazed with your new Mini Avanti Jet ARF ! ..the only aerobatic limit to unlimited fun is your imagination! - Page 2 This warranty does not cover any parts damage by use or modification, and in no case shall SebArt’s liability exceed the original cost of the purchased kit. Further, SebArt reserves the right to change or modify this warranty without notice. In that SebArt has no control over the final assembly or material used for the final assembly, no liability shall be assumed or accepted for any damage of the final user assembled product.
- Page 3 Finally... we hope you have nice flights with this model! SEBART International S.r.l. Via L. Tabellione, 1 47891 Rovereta - Republica di San Marino (RSM) www.sebart.it...
