Replacement Parts List - Masterbuilt 20150108 Assembly, Care & Use Manual

PARTS LIST
8
7
6
13
3
10
4
5
ITEM# QTY DESCRIPTION
1 1 Grill Lid
2 1 Internal Base Pan
3 1 Grill Head/Upper Post
4 1 Middle Post
5 1 Base
6 1 Lid Handle
7 1 Heat Indicator
5
1
2
9
11
14
14
ITEM# QTY DESCRIPTION
8 1 Heat Indicator Shield
(not shown)
9 1 Heat Element
10 1 Control Unit with Cord
11 1 Drip Tray
12 1 Grill Rack
13 1 Serial Plate (not shown)
14 6 Phillips Head Screws
ITEM #
W01EPGBOLTS
W04EPGBPAN
12
W04EPGINBPAN
W00EPGELMT
W01EPGBASE
W01EPGMSTEM
W01PGRDC
W00PGIND
W00PGRING
W00PGPLATE
W00PGGR
W04PGHDLKIT
W04PGLIDR
W00DESCORD
900000298
DO NOT RETURN TO RETAILER
STOP!
For Assembly Assistance, Missing or Damaged Parts
Call: MASTERBUILT Customer Service at 1-800-489-1581.
• Except when loading the grill, must operate with the lid closed.
• Fatty foods (hamburgers, etc.) can have excess grease and cause flare ups.
When cooking fatty foods, use a low setting with lid open.
• Clean internal base pan before each use. This will cut down on build-up and
flare ups.

REPLACEMENT PARTS LIST

DESCRIPTION
Bolt Pack
(6 Phillips Head Screws)
Grill Head/Upper Post
Internal Base Pan
Heating Element
Base
Middle Post
Drip Tray
Heat Indicator
Heat Indicator Shield
Name Plate
Grill Rack
Lid Handle Kit
Grill Lid
Control Unit with Cord
Instruction Manual
CAUTION
6
