CALIBRATE YOUR MAKERBOT DIGITIZER
3 Calibrate the MakerBot Digitizer Camera
Locate the calibration tool from
the accessory box and place it on
the turntable with the letter A pointing
up, as shown on the screen. Insert the
tab on the lower edge of the calibration
tool into the hole at the center of the
turntable. Ensure that the calibration
tool is positioned as shown before
clicking Continue.
4 Calibrate the MakerBot Digitizer Turntable
Flip the calibration tool so that the
letter B points up as shown on the
screen, and insert the tab on the lower
edge of the calibration tool into the hole
at the center of the turntable. Ensure
that the calibration tool is positioned as
shown before clicking Continue.
