Quick Setup - MIDI Keyboard
QUICK SETUP
Using the PROCUSSION with a MIDI Keyboard
These instructions will get you up and running in the shortest amount of
time. Connect Procussion to your sound system and MIDI keyboard as
shown on the following page and turn everything on.
SET LEVELS
1) Turn the Procussion's volume control to minimum.
2) Press the Master button on Procussion.
3) Turn the Data knob clockwise to the very last screen which reads,
"DEMO SEQUENCE".
4) Press the Cursor button to move the flashing cursor to the bottom line
in the display.
5) Press Enter to start the demo sequence, then slowly turn up the volume
control to a comfortable listening level. You may have to adjust the
volume of your sound system. Press Enter again to stop the demo.
PROCUSSION SETUP
The Zone Map function re-maps every kit in Procussion to fit your MIDI
keyboard. This is much easier than having to modify each individual kit.
1) Press the Master button on Procussion.
2) Turn the Data knob to the screen which reads, "ZONE MAPS".
3) Verify that the bottom line of the display reads "Kit". If the display
reads something other than "Kit", press the Cursor button to move the
flashing cursor to the bottom line in the display, then press it again so
that the flashing cursor line is underneath the word in the lower line.
Turn the data knob until it does read "Kit".
4) Press the Master button to return to the main screen.
5) Play your MIDI keyboard. You should now be hearing sound. If not,
verify that the MIDI light on Procussion flashes as the keys are played.
If it doesn't flash, check the MIDI connection.
6) Turn the data knob clockwise to select another kit. Remember,
Procussion has 128 different kits! Have fun.
