Midi Channel Selection; Channel Volume - EMU procussion Operation Manual

18
Channel Selection
BASIC OPERATION
If your Procussion is
not responding properly
or plays the wrong kit,
make sure that
Procussion and your
MIDI controller are set
to the same MIDI chan-
nel and that the MIDI
Volume is turned up.
For more information
about MIDI, see MIDI
Realtime Controls on
page 44.
Channel Pan should
normally be set to "K"
unless realtime control
of panning is desired.
This will allow the
preprogrammed pan
settings for each zone
or stack to be used.
KIT SELECTION
Press the cursor key repeatedly until the cursor is underneath the kit
number. (The cursor is a little flashing line underneath one of the
parameters in the display.) As the data entry control is rotated, the kit
number and name will change. The displayed kit will be assigned to the
displayed MIDI channel. Kit numbers range from 000 to 127.
C01 Vol127 Pan=K
000 Kit Name

MIDI CHANNEL SELECTION

Press the cursor key repeatedly until the cursor is underneath the channel
number. (The cursor is a little flashing line underneath one of the
parameters in the display.) Rotate the data entry control to select MIDI
channel 01-16. As the channel is changed, the display will change to show
the kit, volume and pan associated with the displayed channel.
C01 Vol127 Pan+0
000 Kit Name

CHANNEL VOLUME

Press the cursor key repeatedly until the cursor is underneath the volume
value. Rotate the data entry control to select volume 00-127. (This is the
same parameter as MIDI volume control #7, and changes made over
MIDI will be shown in the display.)
CHANNEL PAN
Press the cursor key repeatedly until the cursor is underneath the pan
value. Rotate the data entry control to select pan values -7 to +7 or "K".
When "K" is selected, the pan value specified in the kit is selected. Any
other value will override the pan parameter in the kit. (This is the same
parameter as MIDI pan control #10, and changes made over MIDI will be
shown in the display.)
Procussion operation manual
÷
MIDI Channel Parameters
÷
Kit Information
