Basic Organization
PROCUSSION INTRO
Procussion is organized as shown in the simplified diagram below.
MIDI
Note # - 36 48
Zone
1
Drum
Stack
Up to 4 Instruments
which can be
controlled or switched
in various ways.
A number of sampled percussion instruments are mapped across a
keyboard or set of drum pads. Each instrument has many individual
attributes such as tuning, volume, pan, etc.
The Kit is a complete set of all program parameters for a set of up to 24
Procussion drum Stacks. There are 128 kit locations in the Procussion.
Kits 0-63 are unalterable factory kits; Kits 64-127 are user kits which can
be changed.
Stacks, which can be made of up to 4 percussion Instruments, are
assigned to MIDI key ranges called Zones. Up to 24 zones may be
assigned in one kit.
The instruments in a stack can be modulated in many ways or switched
on and off depending on various parameters such as velocity (how hard
a drum is played) or perhaps the position of the high hat pedal, sticking
speed, etc.
MIDI Drums
Zone 24
Zone 1
Zone 2
60 72
Zone
2
Drum
Up to 24 Zones
Stack
Up to 4 Instruments
which can be
controlled or switched
in various ways.
PROCUSSION KIT
Procussion operation manual
84 96
Zone
Zones larger than
24
1 note are used for
Tuned Percussion
Drum
Stack
Up to 4 Instruments
which can be
controlled or switched
in various ways.
