Kit Parameters
MIDI SPECIFICATIONS
Please note: In the following tables, the "size" specification refers to the
number of MIDI bytes used when transferring kit data or master settings
as a whole; when sending or reading individual parameter values, two
MIDI bytes are always used.
KIT PARAMETERS
Parameter # Parameter Name
P= 0-11 kit name (12 ascii chars)
12 mod source 1
13 mod dest 1
14 mod amount 1
15 mod source 2
16 mod dest 2
17 mod amount 2
18 footswitch dest 1
19 footswitch dest 2
20 trigger tempo
21 velocity curve
ZONE PARAMETERS
Parameter # Parameter Name
P= 0 stack select
1 low key
2 high key
3 coarse tune
4 fine tune
5 volume
6 pan
7 output
8 assign mode
9 nontranspose
10 enable patch 1
11 enable patch 2
12 enable footswitch 1
13 enable footswitch 2
Procussion operation manual
(T=0)
Size Range
12 32-127
1 0-9
1 0-57
2 -128 to +127
1 0-9
1 0-57
2 -128 to +127
1 0-39
1 0-39
2 0-240
1 0-9
(T=1)
Size Range
2 0- # of stacks
1 0-127
1 0-127
1 -48 to +48
1 -64 to +63
1 0-127
1 -8 to +7
1 0-15
1 0-13
1 0-1
1 0-1
1 0-1
1 0-1
1 0-1
