Options - Icom IC-F29DR Instruction Manual

4

OPTIONS

D BATTERY PACKS
• BP-278/BP-279/BP-280
Battery pack Voltage
BP-278
BP-279
7.2 V
BP-280
* When the power save function is turned ON, and the
operating periods are calculated under the following
conditions:
TX:RX:standby = 5:5:90
D CHARGERS
• BC-213
desktop charger
• BC-214
multi charger
D DC CABLES
• C P-23L
cigarette lighter cable
For BC-213.
• O PC-656
dc power cable
For BC-214.
11
battery pack
Capacity Battery life*
1130 mAh (minimum)
12 hours
1190 mAh (typical)
1485 mAh (minimum)
17 hours
1570 mAh (typical)
2280 mAh (minimum)
26 hours
2400 mAh (typical)
+ BC-123S
ac adapter
+ BC-157S
ac adapter
D OTHERS
• MB-130
vehicle charger bracket
• MB-133
belt clip
• H M-158LA, HM-159LA, HM-168LWP*
HM-168LWP: Waterproof
Adjust the microphone gain before use.
• HM-153LA, HM-166LA
earphone microphone
HS-94LWP*, HS-95LWP*, HS-97
+ VS-4LA
ptt switch cable
/OPC-2004LA
adapter cable
HS-94LWP: Ear-hook type
HS-95LWP: Neck-arm type
HS-97: Throat microphone
VS-4LA: To connect headset and for PTT use
OPC-2004LA: To connect to headsets for VOX operation
Adjust the both microphone and VOX gain before use.
* When in use, the transceiver meets IP67 requirements for
dust-tight and waterproof protection.
Some options may not be available in some countries. Ask your
dealer for details.
Approved Icom optional equipment is designed for optimal
performance when used with an Icom transceiver. Icom is not
responsible for the destruction or damage to an Icom transceiver
in the event the Icom transceiver is used with equipment that is not
manufactured or approved by Icom.
speaker microphone
headset
