Icom IC-F29DR Instruction Manual page 11

D Rapid charging with the BC-214
The BC-214
multi charger
to 6 Li-ion battery packs.
The BC-214 is used with the BC-157S
OPC-656 (purchase separately).
dc power cable
• C harging time of the BP-280
Approximately 3.5 hours
can simultaneously charge up
or the
ac adapter
BATTERY CHARGING
Battery
Transceiver
pack only
+ Battery pack
BC-214
3
Turn OFF the power
BC-157S
OPC-656
Connect to a DC
power supply:
12 to 16 V, at least 7 A
Red line: +
Black line: _
E
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
10
