Instruction manual and maintenance
MONROC
U / GB
Rev. 090129
...............................................................................
...............................................................................

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MONROC and is the answer not in the manual?

Questions and answers

Related Manuals for Expobar MONROC

Summary of Contents for Expobar MONROC

  • Page 1 Instruction manual and maintenance MONROC U / GB Rev. 090129 ................................

  • Page 2: Table Of Contents

    Page 5 Pressure gauge Page 5 Start up Page 5 Fitting the filter holder into the brew group Page 6 Dispensing of coffee MONROC Page 6-7 Control panel 11.1 Programming the electronic control panel Page 8 11.2 Electronic control panel alarms...

  • Page 3: Identification Of External Components

    2. Identification of external components MONROC FIG. 1 3. Water tap 5. Electronic control panel 2. Boiler pressure gauge 1. Steam tap 12. Exit steam spout 6. Indication lamp 7. Adjustable leg 8. General switch 11. Hot water exit 9. Filter holder 10.

  • Page 4: Equipment Provided

    4. Equipment provided MONROC For models: Units 2, 3 and 4. complete filter holders for two cups 1 filter holder for 1 cup. 1 1/2 meter hose. 1 clean unit filter. 5. Installation of the coffee machine MONROC When the machine is installed in its case, the latter must be as near horizontal as possible (use the adjustable legs) so that the coffee issuing from the machine is evenly distributed between the cups.

  • Page 5: Filling Water In The Boiler

    6. Refilling water in the boiler MONROC Water is refilled automatically. 7. Pressure gauge MONROC Indicates pressure in the interior of the boiler Pressure-Temperature Relationship Temperature (ºC) Pressure bars 8. Start up MONROC Open the water screw valve external to the machine.

  • Page 6: Fitting The Filter Holder Into The Brew Group

    9. Fitting the filter holder into the dispensing unit MONROC Water is refilled automatically. FITTING THE FILTER HOLDER INTO THE FIG. 2 DISPENSING UNIT The filter holder has two projections on the sides which must be fitted into the unit’s slots. When that has been done, turn from left to right until the handle of the holder is at a perfect right angle to the coffee machine.

  • Page 7: Dispensing Of Coffee Monroc

    10. Dispensing coffee MONROC CONTROL MODEL Pull the filter holder away from the machine. Place the amount of coffee you need for coffee of your choice in the filter. Preferably, the coffee should have been recently ground. Use the appropriate filter holder See Fig.

  • Page 8: Control Panel

    11. Electronic control panel MONROC 11.1. Programming the electronic control panel Keep pressing the continuous button, on either of the two control panels, for 8 seconds. The continuous coffee lights will blink on and off. Press the coffee dose you want to reprogramme (1 small coffee - 1 large coffee - 2 small coffees - 2 large coffees).

  • Page 9: Electronic Control Panel Alarms

    11. Electronic control panel MONROC 11.2. Electronic control panel alarms When the electronic control panel detects a lack of water in the boiler, the five lights on the control panel will blink. When the volume meter on the electronic control panel detects a problem, the light for the dose which we have pressed blinks.

  • Page 10: Cleaning The Coffee Machine

    14. Cleaning the coffee machine MONROC Cleaning the coffee machine Disconnect the machine for cleaning. The entire surface of the coffee machine can be cleaned with a damp cloth. Use NON-aggressive detergents. Do not use solvents or degreasing agents. 15. Cleaning the dispensing unit...

  • Page 11: We Recommend

    16. We recommend MONROC We recommend · The unit must be cleaned every day without using detergent, only with the membrane and water. · The unit must be cleaned with detergent once a week. Depending on the hardness of the lime, decalcify.

  • Page 12: Possible Dysfunctions

    17. Possible dysfunctions MONROC Possible dysfunctions These malfunctions are caused by lime: The coffee does not emerge at the right temperature: The exit tubes of the exchangers are obstructed by lime. Water fails to issue from the brew groups: 18. Precautions...
  • Page 13 FOR SERVICE Your retail dealer ................................................CREM International AB Box 960, 671 29 ARVIKA, Sweden +46 (0)570-477 00, Fax: +46 (0)570-47719 E-mail: info.se@creminternational.com www.creminternational.com Art. nr/Art. no. 1730041...
