Meter Description

1.
LCD Display
2.
Function switch
3.
10A jack
4.
COM jack
5.
Positive jack
Note: Tilt stand, fuse and battery
compartment are on rear of unit.
LCD Display Indicators
•)))
Continuity
Diode test
m
milli ( volts, amps)
k
kilo (ohms)
ohms
V DC
volts direct current
V AC
volts alternating current
A DC
amps direct current
A AC
amps alternating current
BAT
Low battery and battery test
7
MN25 Version 2.2 Aug 2003
