Bind Type
Server IP Address
Port
Common Name
Identifier
Base DN
Group DN
Regular DN
Regular Password
Logout After(min)
Apply
Cancel
4. Enter all the settings and click Apply.
5. A new LADP/Active Directory Profile has been created.
There are three types of bind type supported.
Simple Mode – Just simply do the bind authentication
without any search action.
Anonymous – Perform a search action first with
Anonymous account then do the bind authentication.
Regular Mode– Mostly it is the same with anonymous
mode. The different is that, the server will firstly check if
you have the search authority.
For the regular mode, you'll need to type in the Regular DN
and Regular Password.
Enter the IP address of LDAP server.
Type a port number as the destination port for LDAP server.
Type or edit the common name identifier for the LDAP
server. The common name identifier for most LDAP server
is "cn"
It means "Base Distinguished Name". Type the
distinguished name used to look up entries on the LDAP
server.
It means "Group Distinguished Name". Type the
distinguished name used to look up entries on the LDAP
server.
Type this setting if Regular Mode is selected as Bind Type.
Specify a password if Regular Mode is selected as Bind
Type.
It means the maximum usage duration for RADIUS
authentication.
Click it to save the configuration.
Click it to exit the dialog without saving the configuration.
