Web Portal - Draytek Vigor3900 User Manual

4 . 7 . 1 W e b P o r t a l
4 . 7 . 1 W e b P o r t a l
Web Portal is a gateway which organizes the network access of LAN hosts. The identity of
LAN host can be recognized by web portal mechanism and then be managed for functions
like firewall or load balance.
This page can determine the general rule for the users controlled by User Management. The
mode selected in this page will influence the contents of the filter rule(s) applied to every
user.
4 . 7 . 1 . 1 O n
4 . 7 . 1 . 1 O n
The Online User Status is a monitoring tool which only works after you choose HTTP or
HTTPS as the Mode setting on General Setup page of User Management>>Web Portal.
Refer to section 4.7.1.2 General Setup to get more detailed information of setting web portal.
Available parameters will be explained as follows:
Item
Refresh
Auto Refresh
User Name
IP
Allow Time
l i n e U s e r S t a t u s
l i n e U s e r S t a t u s
Description
Renew current web page.
Specify the interval of refresh time to obtain the latest status.
The information will update immediately when the Refresh
button is clicked.
Display the name information for the user who logs into the
WUI of Vigor3900.
Display the IP address of the user who logs into the WUI of
Vigor3900.
Display the total network connection time allowed for the
258
Vigor3900 Series User's Guide
