Draytek Vigor167 Quick Start Manual

35b modem
Hide thumbs Also See for Vigor167:

Advertisement

Quick Links

Download this manual
Vigor167
35b Modem
Quick Start Guide
Version: 1.2
Firmware Version: V5.2.4
(For future update, please visit DrayTek web site)
Date: March 5, 2024
i

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vigor167 and is the answer not in the manual?

Questions and answers

Related Manuals for Draytek Vigor167

Summary of Contents for Draytek Vigor167

  • Page 1 Vigor167 35b Modem Quick Start Guide Version: 1.2 Firmware Version: V5.2.4 (For future update, please visit DrayTek web site) Date: March 5, 2024...
  • Page 2 We reserve the right to revise the manual and online documentation and to make changes from time to time in the contents hereof without obligation to notify any person of such revision or changes. Model: Vigor167 Power Consumption：4.4W (Max.) Power Input: 12V 0.4A...
  • Page 3 EU Declaration of Conformity Hereby, DrayTek Corporation declares that the equipment type Vigor167 is in compliance with EU EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU and RoHS 2011/65/EU. The full text of the EU Declaration of Conformity is available at the following internet address: https://fw.draytek.com.tw/Vigor167/Document/CE/...
  • Page 4 81.3% 83.3% 83.7% 74.5% 80.5% 86.4% 85.4% 85.4% 84.7% 87.7% low load 10% No-load power 0.07W 0.07W 0.07W 0.07W 0.07W 0.07W 0.10W 0.07W 0.10W 0.10W 0.08W 0.10W consumption External power supply (Power Adapter) information. For more updates, please visit www.draytek.com.

  • Page 5: Table Of Contents

    1. Package Content ....................1 2. Panel Explanation....................2 3. Hardware Installation ................... 3 3.1 Network Connection ........................3 3.2 Wall-Mounted Installation ......................4 4. Software Configuration ..................5 5. Customer Service ....................9...

  • Page 6: Package Content

    Take a look at the package content. If there is anything missed or damaged, please contact DrayTek or dealer immediately. Modem Quick Start Guide RJ-45 Cable (Ethernet) RJ-11 to RJ-11 Cable or RJ-11 to RJ-45 Cable The type of the power adapter depends on the country that the modem will be installed.

  • Page 7: Panel Explanation

    Status Explanation The system is not ready or is failed. Blinking The system is ready and can work normally. P1/P2 A normal connection is through its corresponding port. LAN is disconnected. Blinking Data is transmitting (sending/receiving). xDSL connection synchronized. Blinking xDSL connection is synchronizing.

  • Page 8: Hardware Installation

    This section will guide you to install the modem through hardware connection and configure the modem’s settings through web browser. Before starting to configure the modem, you have to connect your devices correctly. Connect the DSL interface to the MODEM port of external splitter with a DSL line cable.

  • Page 9: Wall-Mounted Installation

    Vigor167 has keyhole type mounting slots on the underside. Drill the holes on the wall according to the recommended instruction. Fit screws into the wall using the appropriate type of wall plug. Note The recommended drill diameter shall be 6.5mm (1/4”).

  • Page 10: Software Configuration

    To access the Internet, please finish the basic configuration after completing the hardware installation. Make sure your PC connects to this device correctly. Note Please set up the IP address of the computer to be the same subnet as the default IP address of Vigor device 192.168.1.1.
  • Page 11 Now, the Main Screen will pop up. 1. Open Operation Mode to open the following page. Select Modem Mode and click Next.
  • Page 12 2. In this page, configure the system time settings. Then click Next. 3. For the Internet connection, configure the settings based on the information from your ISP. Then click Next to get the next page.
  • Page 13 4. From the following page, change LAN settings if required. Then click Next. 5. Now, click Apply & Reboot to activate the settings.

  • Page 14: Customer Service

    Web registration is preferred. You can register your Vigor modem via https://myvigor.draytek.com. Firmware & Tools Updates Due to the continuous evolution of DrayTek technology, all devices will be regularly upgraded. Please consult the DrayTek website for more information on the newest firmware, tools, and documents.
