Limit Packets
Limit Mode
Next Group
Syslog
Input Interface
Output Interface
Time Schedule
Service Protocol
Vigor3900 Series User's Guide
When you choose Connection Limit as Action, you have to
configure limit packets number to determine how many
packets per second will be passed through.
When you choose Connection Limit as Action, you have to
choose Share or Each in addition to the number of packets
limits.
Share – It means the total IP addresses in a segment will be
limited with certain packets number per second.
Each –It means each IP will be limited with certain packets
number per second.
When you choose Block If No Further Match or Accept If
No Further Match as Action, you have to specify next IP
filter group for further matching.
Click Enable to make the history of firewall actions
appearing on the System Maintenance >> Syslog/Mail
Alert >> Syslog File.
Choose one of the LAN or WAN profiles as data receiving
interface.
Choose one of the LAN or WAN profiles as data
transmitting interface.
Time Object - Click the triangle icon
profile selection box. Choose a schedule object profile to be
applied on such rule. You can click
new time object profile.
Time Group - Click the triangle icon
profile selection box. Choose a schedule group profile to be
applied on such rule. You can click
new time group profile.
Service Type Object –Click the triangle icon
the profile selection box. Choose one or more service type
object profiles from the drop down list. The selected profile
will be treated as service type. You can click
another new service type object profile.
Service Type Group –Click the triangle icon
189
to display the
to create another
to display the
to create another
to display
to create
to display
