1. Open Objects Setting>> Service Type Object.
2. Simply click the Add button.
3. The following dialog will appear.
Available parameters are listed as follows:
Item
Profile
Protocol
Source Port Start
Source Port End
Destination Port
Start
Destination Port
End
Apply
Cancel
4. Enter all the settings and click Apply.
5. A new Service Type Object profile has been created.
Vigor3900 Series User's Guide
Description
Type a name for such profile. The number of the characters
allowed to be typed here is 10.
Specify one of the protocols for such profile.
It is available for TCP/UDP protocol. It can be ignored for
ICMP.
Type a port number (0 – 65535) as the starting source port.
It is available for TCP/UDP protocol. It can be ignored for
ICMP. Type a port number (0 – 65535) as the ending source
port.
It is available for TCP/UDP protocol. It can be ignored for
ICMP.
Type a port number (0 – 65535) as the starting destination
port.
It is available for TCP/UDP protocol. It can be ignored for
ICMP. Type a port number (0 – 65535) as the ending
destination port.
Click it to save the configuration.
Click it to exit the dialog without saving anything.
