PARTS IDENTIFICATION

1
6
13
12
11
10
14
1 Variable speed selector
2 On/Off trigger switch
3 Lock-On button
4 Handle
5 Mains cable
6 Cooling vents
7 Dust extraction port
8 Base plate adjustment
9 Base plate screw
15
17
10 Anti-scratch base plate cover
11 Parallel fence guide fixing screws
12 Blade guard
13 Pendulum adjustment lever
14 Hexagonal key
15 Anti-splinter insert
16 Dust extraction port adaptor
17 Parallel fence guide
18 Carrying/storage case
