FITTING THE ANTI-SPLINTER
INSERT
10
The-anti splinter insert should be fitted to the base plate when cutting
wood. The insert can only be used when the base plate is in the 90
position. To fit the insert, press it upwards from below, into the recess
provided in the base plate. To remove the insert push it down and out
of the base plate.
FITTING THE ANTI-SCRATCH
BASE PLATE COVER
The anti-scratch base plate cover is supplied to prevent damage to
the surface of delicate, or fragile materials. To fit it, place it over the
metal base plate and push firmly until it snaps into place. To remove
the cover, carefully lever out the end clips.
Base
plate
End clips
Anti-
splinter
insert
Base plate
cover
Anti-splinter
insert
