4-3. Remote 14 Receptacle Information
A
A
J
J
K
I
B
C L N
C L N
H
H
M
D
G
F
F
E
*The remaining sockets are not used.
4-4. Optional 115 Volt AC Duplex Receptacle And Circuit Breakers
24 VOLTS AC
24 VOLTS AC
115 VOLTS AC
115 VOLTS AC
REMOTE
OUTPUT
OUTPUT
CONTROL
A/V
A/V
AMPERAGE
VOLTAGE
GND
GND
1
Socket*
Socket Information
A
24 volts ac. Protected by circuit breaker CB2.
B
Contact closure to A completes 24 volts ac
contactor control circuit.
I
115 volts ac. Protected by circuit breaker CB1.
J
Contact closure to I completes 115 volts ac
contactor control circuit.
C
Output to remote control; +10 volts dc.
D
Remote control circuit common.
E
0 to +10 volts dc input command signal from
remote control.
F
Current feedback; +1 volt dc per 100 amperes.
H
Voltage feedback; +1 volt dc per 10 output recep-
tacle volts.
G
Circuit common for 24 and 115 volts ac circuits.
K
Chassis common.
1
Power is shared between duplex
receptacle and Remote 14 recep-
tacle (see Section 4-3).
2
CB1 protects duplex receptacle
and 115 volt ac portion of Remote
14 receptacle from overload.
3
CB2 protects 24 volt ac portion of
Remote
overload.
Press button to reset breaker.
2
3
115 V 10 A AC Receptacle
Circuit Breaker CB1
Circuit Breaker CB2
14
receptacle
from
ST-801 245-A
OM-188 304 Page 15
