1. Press the <Utility> button and scroll to Page 4 of the Utility menu using the <Page> knob. The display reads:
2. Use the <3> knob to select the MIDI Preset change number you want mapped. Note that the number under Millennium USER changes
along with the MIDI number.
3. Use the <4> knob to select the Millennium Preset you want the selected MIDI Preset change number to recall. As this number increases
above Preset 100, note that Millennium USER changes to Millennium FACT, indicating that the mapped number will recall the indicated
Preset number in the Factory bank..
Preset Transmit Map
With the Preset Transmit Map function, you can use your Millennium to send MIDI patch changes of your other effects devices. When you call
up a preset in your Millennium, the appropriate presets in your other FX unit's will also be recalled.
To remap a MIDI Preset change number to a preset number, do the following:
1. Press the <Utility> button,and scroll to Page 5 of the Utility menu using the <Page> knob. Now use the <1> knob and turn the setting
to On . The display will now appear like this:
2. Use the <3> knob to select the Millennium preset number you want mapped. Note that the number under MIDI changes along with the
preset number.
3. Use the <4> knob to select the MIDI preset change number to be sent out the MIDI Out port when the corresponding preset number is
recalled.
SysEx Device Channel
An easy way to think of the System Exclusive Device channel option is to separate System Exclusive data from normal MIDI data. Each type of
data has its own group of 16 channels upon which data can be transmitted. This feature will also allow individual remote control of more than
one Millennium with SysEx commands.
From the Factory and in most situations, the SysEx channel is set at Channel 1.
User Guide
2
Prg Rcv Map:MIDI= User
%kHz %kHz
2 3
msdB msdB
LINK CHANGED LINK CHANGED LINK
WAH TUBE EQ GATE
FACTORY USER
#
b
BANK 4 16
PAGE OF
2
PrgTrans Map:User=MIDI
%kHz On %kHz
2 3
msdB msdB
LINK CHANGED LINK CHANGED LINK
WAH TUBE EQ GATE
FACTORY USER
#
b
BANK
5 16
PAGE OF
Section - 5 Advanced Topics
1 %kHz 1
4
msdB
CHANGED LINK CHANGED
L/R OUTS
L/R OUTS
1 %kHz 1
4
msdB
CHANGED LINK CHANGED
L/R OUTS
L/R OUTS
