External Expression Pedals

The rear panel of the Millennium contains 2 external expression pedal inserts that can be linked to control any parameter of the Amplifiers'
operating system. Either a standard volume or a voltage control pedal can be connected to these insertion jacks. The 2 external expression
pedals on the J-12 foot controller can be used as well.
Once the external expression pedal is connected, the assignment procedure to be followed is listed below.

Linking a Parameter to a Modifier

To link a parameter to a modifier, please complete the following steps:
1. Scroll to the parameter you would like to link to a modifier (ie: Delay feedback).
2. Press the <Assign> twice when using a foot controller button and the display appears something like:
3. Turn the <1> knob to turn the link for the selected parameter on. The display will look something like this:
4. Use the <2> knob to scroll through the different modifiers that can be linked to the parameter you want assigned. The selections are:
MIDI CC's (CC): 0-127 & ChP (aftertouch)
Real Time modifiers (RT): LF1, LF2, dY1, & dy2
External Pedal (Ext): Pdl,(Pd3) when the J-12 is connected.
J-12 (F.Pdl & F.Sw): Pdl-2 & F l-10
NOTE: The MUTE and THRU effect types do not have any Parameters to connect to, so they will not appear in the parameter list.
5. Use the <3> knob to select the minimum parameter value you want when the controller is in the maximum position.
6. Use the <4> knob to select the maximum parameter value you want when the controller is in the maximum position.
User Guide
2
Avail Link for: FdBack
OFF %kHz
1
msdB
LINK CHANGED LINK CHANGED
WAH
FACTORY USER
b
BANK
1 4
PAGE OF
2
FdBck F.Sw
on %kHz F1
1 2
msdB
LINK CHANGED LINK
WAH
FACTORY USER
b
BANK 1 19
PAGE OF
NOTE: Make sure you store any changes you want to save before moving on.
Section - 5 Advanced Topics
LINK CHANGED LINK CHANGED
TUBE EQ GATE
L/R OUTS
#
L/R OUTS
Min[ ]Max
%kHz -99 %kHz Hld %kHz
3 4
msdB msdB msdB
CHANGED LINK CHANGED LINK CHANGED
TUBE EQ GATE
L/R OUTS
#
L/R OUTS
