Section - 4 Editing Modules
Multi-Effect Module Parameters
FX: Lvl
Dry: Lvl
Balance
Route
Speed
Depth
Feedback (Flanger)
WvFrm
C/F: Delay
Delay Time
Feedback
TapIt
Level: C/F/D
Pan: C/F/D

Whammy Effects

In today's music industry, it seems that every album on the charts, whether it be Country, Rock, Industrial, or Alternative, are using the
Whammy technology in some shape or form. Whether it be a subtle chorus Detune, or an all out 2 octave Whammy Dive, this thing is a definite
attention getter, and first-call studio effect. At this rate, the Whammy effect could possibly log-in as much studio time as Chet Atkins.
54
Controls the signal input level fed to the Module. Ranges from Off to 100%.
Controls the level of the dry (uneffected) signal. Ranges from Off to 100%.
Controls the positioning of the dry signal in the stereo soundfield. Ranges from -99 (all left) to 99 (all right).
Selects the route signal path within the Chorus/Delay, and Flange/Delay Multi effects modules. The 3 settings are: 1)
Chorus/Flange into Delay with feedback into the Delay 2) Chorus/Flange into Delay with feedback into Chorus/Flange
3) Delay into Chorus/Flange with feedback thru the Chorus/Flange.
Controls the Low Frequency Oscillator (LFO) Speed of the Chorus or Flanger. Ranges from 0.06 to 16.0 Hz.
Adjusts the intensity of the Chorus or Flanger effect. Ranges from 0 to 30 milliseconds.
Controls how much of the flanged signal is fed back to the input of the Module. The FDBACK Parameter is what gives
flangers their distinctive voice. Flangers are capable of both positive and negative feedback loops, so experiment to
find the sound you like best. Ranges from -99% to 99%.
Selects which waveform the LFO follow. Options for this control include: Sine, Triangle, SP1 (Special 1), and SP2
(Special 2).
Controls the delay time of the Chorus or Flanger voice. Ranges from 0 to 40 milliseconds.
Sets the delay time for the delay tap. Ranges from 0 to 300 milliseconds.
Controls the fade time of the delay repeats. Higher settings take longer to fade out, while a setting of zero will limit
the delay to one repeat. Ranges from 0 to 99%.
Allows you to change the Delay time in real-time by tapping the TAPIT button at the tempo you want. Delay voice
percentages do not change when using this control.
Controls the overall output level of each effect block. Ranges from Off to 100%.
Controls the stereo soundfield placement of each effect block. Ranges from -99 (all left) to 99 (all right).
