Section - 3 Editing Presets
3. The <2> button (pedal parameter) can be assigned to a footswitch to bypass or turn the module On. This parameter can be selected by
turning the <2> knob and a Changed icon will appear directly beneath the parameter. At this point press the <Assign> button and
the display will appear as follows:
4. Now press the footswitch to be assigned. You can use either a standard volume or voltage controlled Expression pedal connected
to the Expression pedal I and 2 pedal inserts on the rear panel of the Millennium or you can use either one of the Expression
pedals on the optional J-12 Foot Controller to act as the Wah pedal. If the selected footswitch is already assigned to control another
parameter, the display of the Millennium will ask you if you want to re-assign. If you wish to re-assign, turn the <1> knob for yes or the
<2> knob to abort the assign function.
Note: Any time an assignment to turn a parameter On/Off is made you must decide if you want the parameter On when you enter the
selected preset. If you want it on, make the assignment to the parameter when the parameter is set to On. Otherwise, have the
parameter set to Off or Bypass and the parameter will not be active within the Preset until the footswitch is used to activate the
parameter
5. To Exit the Analog Wah edit mode, simply press the <Preset> button.
Noise Gate Editing
The procedure for editing the Noise Gate module within the Integrated amplifier section is as follows:
1. From Preset mode, press the <Edit> button and turn the <Preset/Effect> wheel until the display appears something like this:
2. At this point, you can use the <1> knob to turn the Noise gate On or Off and the <4> knob is used to select the Noise gate default.
3. Now use the <Page> knob and turn to page 2 of the Noise Reduction module. Turning the <1> knob lets you select the Noise gate type
and its position in the signal flow.
26
2
Avail Link for: Pedal
OFF
1
LINK CHANGED
WAH
USER
b
BANK
1 19
PAGE OF
2
Noise Gate
On
1
LINK CHANGED
WAH
USER
b
BANK
1 3
PAGE OF
LINK CHANGED LINK CHANGED LINK CHANGED
TUBE EQ GATE
#
DIGITAL
S1Pre Gate
F 1
2 4
LINK CHANGED LINK CHANGED LINK CHANGED
TUBE EQ GATE
#
DIGITAL
Johnson Millennium
L/R OUTS
L/R OUTS
User Guide
