Section - 5 Advanced Topics
4. Now using the <Page> knob, turn to page 2 and the display will appear like this:
5. By turning the <3> this will activate the Morph pedal parameter making it ready for assignment. Now press the <Assign> button and the
display will appear something like this:
6. Now select the expression pedal to be assigned. This can be either one of the two expression pedal inserts located on the rear of the unit,
or one of the two expression pedals on the J-12 foot controller and the display will appear something like this:
7. In this example, Expression pedal 1 of the J-12 is now assigned to morph between Solid State and Tube distortion models. Note that -99 as
the minimum value represents the Solid State (bottom) Amp and the maximum being 99, represents the Tube (top) distortion. To return
to Preset mode, press the <Preset> button. Always remember to save any changes.
Morphing Between Effect Modules
Not only does the Millennium allow you to morph between Amplifier modules, but it also gives you the ability to morph between effect
modules. This can be done when using Effect Configurations 6, 12 or 15 which are split configurations.
The procedure for assigning the morph pedal to the effect modules uses the same steps as 3 through 7 of the Amplifier Morphing assignment
procedure.
Volume Pedal Assignments
Volume control can be assigned to any preset within the Millennium. When volume control is used in a selected preset, you have the option of
using either one of the two Expression pedal inserts (located on the rear of the unit), or the expression pedal available on the optional J-12 foot
controller.
The procedure for assigning volume control to any preset of the Millennium is as follows:
60
2
Vol Pdl Morph Pdl
%
1 100
LINK CHANGED LINK CHANGED
WAH TUBE EQ
DIST EQ
FACTORY USER
#
b
BANK
2 2
PAGE OF
2
Select a Contrl F.Switch
LINK CHANGED LINK CHANGED LINK
WAH TUBE EQ
DIST EQ
FACTORY USER
#
b
2
Morph Exp 1 Min [99] Max
On 0
1 2
LINK CHANGED LINK CHANGED
WAH TUBE EQ
FACTORY USER DIST EQ
#
b
1 19
PAGE OF
%
3 0
LINK CHANGED
GATE
L/R OUTS
L/R OUTS
CHANGED
GATE
L/R OUTS
L/R OUTS
-99 99
3 4
LINK CHANGED
GATE
L/R OUTS
L/R OUTS
