Johnson Millennium
When ww= 7F(h)
When ww= 68(h)
ww
When a Request All Current Parameter Values procedure is received, the Millennium will respond with a Respond All Current Parameter
Values procedure.
RECEIVE ALL CURRENT PARAMETER VALUES FOR CURRENT PRESET (24h)
SYS_HEAD, 24(h), nn1, nn2, ww1, ww2, mm1(1st), mm2(1st), aa1(1st), aa2(1st), dd1(1st)(1st), dd2(1st)1st, ... dd1(1st)(wth) ,dd2(1st)(wth),
... mm1(xth),...mm2(xth), aa1(xth), aa2(xth), dd1(xth)(1st), dd2(xth)(1st), ... dd1(xth)(wth),dd2(xth)(wth), F7(h)
When ww= 7F(h)
When ww= 68(h)
nn
ww
mm
aa
dd
The Receive All Current Parameter Values procedure is used to receive Parameter Values from the Millennium for the currently selected
program.
Warning: Sending data that was retrieved from a different preset will delete the memory. Be sure to only send data that was received from
the same preset.
REQUEST MODULE CONFIGURATION (25h)
SYS HEAD , 25 (h) , F7 (h)
When a Request Module Configuration procedure received, the Millennium will respond with a Respond Module Configuration procedure.
RESPOND MODULE CONFIGURATION (26h)
SYS HEAD , 26(h) , nn1, nn2, cc(1st)1,cc(1st)2, ee(1st)1, ee(1st)2, ... cc(nth)1, cc(nth)2 , ee(nth)1, ee(nth)2, F7(h)
nn
cc
ee
Class I.D. Numbers for millennium
00(h)
01(h)
User Guide
All module's parameters will be requested.
(position of the module minus 1), only that module's parameters will be requested.
Requested Module's parameter Values
All module's parameters will be received.
(position of the modules minus 1), only that module's parameters will be received.
Number of Modules.
Modules User requested.
Indicates the beginning of the xth Module.
Number of available parameters in the FX Module.
Current value for the wth parameter.
Number modules present in the algorithm
Class I.D. of the nth module in the algorithm
I.D. number of the effect currently loaded in the nth module (see pg. 12 for ID numbers)
Amplifier Type
1/4 Effect Module
Section - 7 Appendix
93
