Section - 5 Advanced Topics

MIDI Functions

In this day and age where the role of the Guitarist has taken on so many new responsibilities, his or her equipment has to be fast, and has to be
able to communicate with other devices at the drop of a hat. So, we at Johnson Amplification have made the Millennium a fully MIDI
implemented device.

Setting the MIDI Channels

This option sets the MIDI Channel that the Millennium will respond to MIDI preset changes and CC messages and transmit preset changes on.
MIDI channel settings include: Off, 1, 2,...15, 16, and All.
To change the MIDI channel assignment, do the following:
1. Go to Page 3 of the Utility menu by pressing the <Utility> button and then turn the <Page> knob. The display reads:
2. Use the <2> knob to select the MIDI channel number you want your Millennium to receive on.
3. Use the <4> knob to select the MIDI channel number you want your Millennium to transmit on.

MIDI Merging

MIDI merging allows incoming MIDI data to be merged with any MIDI data generated by your Millennium before being sent to the MIDI
Out/Thru port. Selecting the MIDI Merge option can be accessed in Page 6 of the Utility menu. Once there, the display will look like this:
Preset Receive Map
The Preset mapping features of the Millennium allow you to access any of your Millennium's 200 Presets using the standard 128 Preset Change
commands through MIDI. From the Factory, the Millennium is set to access User Preset 1 through 100 using MIDI Preset change numbers 1
through 100. MIDI Preset change numbers 101 through 128 access the Factory Preset bank.
To gain MIDI access to other presets not mentioned and bypass you must use the preset mapping feature.
To remap a preset number to a MIDI Preset change number, do the following:
62
2
MIDI: RcvChnl
%kHz 1 %kHz
2
msdB msdB
LINK CHANGED LINK CHANGED LINK
WAH TUBE EQ GATE
FACTORY USER
#
b
BANK
3 16
PAGE OF
2
SysEx Channel
1
1 2
LINK CHANGED LINK CHANGED
WAH TUBE EQ
FACTORY USER
#
b
16
6
PAGE OF
TransChnl
%kHz 1
4
msdB
CHANGED LINK CHANGED
L/R OUTS
L/R OUTS
MIDIMerge
OFF
3 4
LINK CHANGED LINK CHANGED
GATE
L/R OUTS
L/R OUTS
