1
7
3
2
9
10
1) System Box
2) Handle and S-Rod
3) Right/Left Armrest
Components
4) Armrest Strap
5) Search Coil
6) Telescopic Shaft
7) Bolts, Nuts and
Washers
8) 3 Cable Clamps
9) 4 AA Batteries
10) Headphones
5
7
NOKTA DETECTORS
PAR TS a nd ASSE MB LY
7
4
6
8
7
w w w. no ktade tec tors.com
Attach the right/left armrest components to the
S-rod with the bolts and nuts as seen in the
picture. Do not tighten the nuts but rather leave
them loose (these will be tightened after the
system box is attached).
Place the system box on the rail behind the
armrest and push forward. Then secure by
tightening the nuts. Attach the armrest strap
by inserting it through the holes.
FORS / Page 4
