System Light (PC1555RKZOnIy):
If the System light is ON, one or more of these conditions
could be present on the system: --
^ ^,.,,E wEE«.
System Busy ^ ^ . - [^
-^^- , ,^,,.
System Troubles (see 'Viewing Trouble Conditions' on page 11).
Alarm Memory (see 'Disarming the System' on page 6).
Memory Light / Message
Zone Bypassing (see 'Zone Bypassing' on page 11). Upon disarming, if an alarm has occurred while the
Programming
The System light will flash when you are system was armed, the Memory light will turn ON (see
programming access codes, or performing other "Disarming the System" on page 6).
programming functions. If someone is programming
at Bypass Light / Message
another keypad, the System light will turn ON to indicate that If the Bypass light is ON, one or more zones are
the system is busy. bypassed (see "Zone Bypassing" on page 11).
NOTE: If you have a PC1555RKZ keypad, the System
light acts as a Trouble, Memory, Programming and Fire Light / Message
Bypass indicator. Unlike the other keypads, these
If the Fire light is ON, a fire alarm has occurred (see
conditions will only be represented by the System light. "Fire Alarm Operation" on page 14).
Please keep this in mind when reading other functions in Program Light / Message
this manual.
The Program light will flash when you are
Emergency Keys (PC1555RKZ)
programming access codes, or performing other
Press the [F]' key for 2 seconds to send a FIRE programming functions. If someone is programming
transmission. at another keypad, the Program light will turn ON to
indicate that the system is busy.
Press the [A]* key for 2 seconds to send an AUXILIARY
transmission.
PC5516Z LED Keypad
Press the [P]" key for 2 seconds to send a PANIC
transmission.
^• PC5532Z LED Keypad
The PC5516Z and PC5532Z Keypads
are available for applications with more
than 8 zones. The functions explained in
this manual are the same for all three LED
keypad types.
