WARNING
This manual contains information on limitations regarding product use and function and information on the
limitations as to liability of the manufacturer. The entire manual should be carefully read.
Installation
Manual
PC1565
Software Version 2.5U
DLS-3 v1.2 and higher

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Power632 PC1565 and is the answer not in the manual?

Questions and answers

Related Manuals for DSC Power632 PC1565

Summary of Contents for DSC Power632 PC1565

  • Page 1 WARNING This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire manual should be carefully read. Installation Manual PC1565 Software Version 2.5U DLS-3 v1.2 and higher...

  • Page 3: Table Of Contents

    Ta ble of Contents Section 1: System Introduction 5.3 Zone Attributes ..............16 1.1 Specifications ................1 5.4 Assigning Keypad Zones ..........17 1.2 Additional Devices ..............2 5.5 Communicator – Dialing ..........17 1.3 Out of the Box ...............2 5.6 Communicator – Account Numbers ......17 5.7 Communicator –...
  • Page 4 PC1565 Wiring Diagram...

  • Page 5: Section 1: System Introduction

    Se c tion 1: Sy s t e m Int ro du c ti on Specifications Digital Communicator Specifications • Supports major communication formats including SIA Downloading Software Support and Contact ID • PC1565 v2.5U uses DLS-3 v1.2 and up. •...

  • Page 6: Additional Devices

    Additional Devices Out of the Box In addition to the information below, see the back cover for a Please verify that the following components are included in DSC module compatibility table. your system: • one main control cabinet PC5132 Wireless Receiver •...

  • Page 7: Section 2: Getting Started

    After you have attached the The High Current /Standard Battery Charge option (section cabinet to the wall, stick the provided DSC logo sticker on the [701], option [7]) allows you to choose between a high current front of the cabinet.

  • Page 8: Keybus Operation And Wiring

    Programmable Output Terminals – PGM1 and PGM2 • Shielded wire should not be used. Each PGM output is designed so that when activated by the Example of Keybus Wiring panel, the terminal will switch to ground. NOTE: PGM1 can sink up to 300mA of Module (A) is correctly (ANY OUTPUT current.

  • Page 9: Supervision

    G e t t i n g S t a r t e d : 2 . 6 S u p e r v i s i o n How to Program Function Keys Normally Closed (NC) Loops By default, the 5 function keys on each keypad are pro- ANY Z ANY Z ANY COM...

  • Page 10: Fire Zone Wiring

    Loop Resistance Loop Status GSM1000 Supervision (24-hr Supervisory) When using the GSM1000 0Ω (shorted wire, loop shorted) Fault cellular communicator, any 5600Ω (contact closed) Secure main board zone may be Infinite (broken wire, loop open) Tamper configured for GSM1000 11200Ω (contact open) Violated Supervision.
  • Page 11 G e t t i n g S t a r t e d : 2 . 1 2 K e y p a d Z o n e s Assigning Keypad Zones When using keypad zone inputs, each input used must be assigned a zone number in Installer’s Programming.

  • Page 12: Section 3: Keypad Commands

    Section 3: Keypad Commands Use any system keypad to enter commands and/or program Automatic Arming the PC1565 security system. The LED keypad uses function The system can be programmed to Auto-Arm at a specific and zone indicator lights to represent alarm functions and sta- time every day if it is in the disarmed condition.
  • Page 13 K e y p a d C o m m a n d s : 3 . 5 [ * ] C o m m a n d s If the Code Required for Bypass option is enabled (section the trouble beep for faults and tampers by entering an access [015], option [5]), only access codes with the bypass attribute code.
  • Page 14 Light Trouble Device Low Battery: A wireless device has a low battery condition. Press [7] one, two, or three times to view which devices are experiencing battery failure. An LED keypad will indicate battery failure using zone lights 1 to 8. The follow- ing will occur: Keypad beeps: Keypad displays: Press [7]...

  • Page 15: Function Keys

    K e y p a d C o m m a n d s : 3 . 6 F u n c t i o n K e y s time, the panel will answer incoming downloading calls [*][0] Quick Arm (see section 5.10 “Downloading”...

  • Page 16: Features Available For The Lcd5500Z

    [00] Null Key: The key is not used and will perform no Features Available for the LCD5500Z function when pressed. These features are only available for LCD5500Z keypads with [01]-[02] For future use zone inputs: [03] Stay Arm: As described above. Automatic Scrolling of Alarms in Memory [04] Away Arm: As described above.

  • Page 17: Section 4: How To Program

    Se c t ion 4 : H o w t o P ro g r am The following section of the manual describes the Installer’s Programming Decimal Data Programming function and how to program the various sec- A set number of programming boxes are allotted for each sec- tions.

  • Page 18: Programming Toggle Option Sections

    Programming Toggle Option Sections The keypad displays the information using a binary format, according to the following chart: See Hex data Some programming sections contain several toggle options. entry instructions The panel will use zone lights 1 through 8 to indicate if the dif- ferent options are enabled or disabled.

  • Page 19: Section 5: Program Descriptions

    Section 5: Program Descriptions The following section explains the operation of all programma- should be disarmed. If the panel is disarmed before the entry ble features and options and provides a summary of all corre- time expires, no alarm will be generated. sponding programming locations.

  • Page 20: Zone Attributes

    A violated Fire zone will be displayed on all keypads and can [24] For future use be delayed at any keypad. Typically this zone is used for [25] Interior Delay Zone latching smoke detectors. This zone type is normally used with motion detectors and has [08] Standard 24-hr Fire Zone a standard exit delay time.

  • Page 21: Assigning Keypad Zones

    P r o g r a m D e s c r i p t i o n s : 5 . 4 A s s i g n i n g K e y p a d Z o n e s Delay Period (see section 5.15 “Transmission Delay”...

  • Page 22: Communicator - Reporting Codes

    ber is the secondary number and the Third Telephone Num- Zone Restorals ber will back up the First telephone number if enabled. If the Restoral on Bell Time-out option is selected, the panel will send the Zone Restoral Reporting Code for the zone if NOTE: The Third Telephone Number will NOT back up the the bell cut-off time has expired and the zone is secured.

  • Page 23: Communicator - Reporting Formats

    P r o g r a m D e s c r i p t i o n s : 5 . 9 C o m m u n i c a t o r – R e p o r t i n g F o r m a t s of minutes programmed for the AC Failure Communication 2.

  • Page 24: Downloading

    Zone 3). The user must then press a key (1, 2, 4, 5, 7, 8, 0, * or If the Answering Machine/Double Call option is enabled (or #) to acknowledge the alarm. If the panel has another alarm to during the first six hours after power up), the panel will answer communicate, it will sound a corresponding number of beeps incoming calls for downloading in the following manner: for the new zone alarm.

  • Page 25: Pgm Output Options

    P r o g r a m D e s c r i p t i o n s : 5 . 1 1 P G M O u t p u t O p t i o n s 5.11 PGM Output Options [1]...Service Required (battery, bell, general trouble, general tamper, general supervisory)

  • Page 26: Telephone Line Monitor (Tlm)

    is restored. The output will also deactivate if someone arms PGM Output Attributes the system after the Bell Cut-off has expired. In addition to programming the output type, you must also program the PGM output attributes for each output. NOTE:This output will activate for all silent and audible alarms PGM output options [09] “System Trouble”...

  • Page 27: Bell

    P r o g r a m D e s c r i p t i o n s : 5 . 1 3 B e l l When the Bell Delay option is enabled with the system armed, in Minutes/Days allows you to select whether the Land Line and the alarm that initiates the Bell Delay occurs after a TLM Test Transmission cycle will be counted in minutes or days.

  • Page 28: Arming/Disarming Options

    NOTE:The Fire, Auxiliary, Panic keys will operate even if Keypad If the Exit Delay Termination option is enabled, the panel will Blanking is active (See section 5.23 “Keypad Blanking” on page monitor the Delay zones during exit delay. During the exit 25).

  • Page 29: Keypad Lockout Options

    Installers or central station operators will need to have DSC’s The Auto Arm Cancellation code is not transmitted when a Remote Reset software package installed in order to provide reset is required because a user has not cancelled the auto users with the Reset Code.

  • Page 30: Additional System Modules

    nicating an event using the land line. To program this option, 5.28 Engineer's Reset select both the telephone number and GSM1000 options in If the Engineer’s Reset option is enabled, if the panel has the Communicator Call Direction options. The GSM1000 is gone into alarm during the previous armed period, or if a 24-hr Backup of Land Lines option must be selected.

  • Page 31: Installer's Lockout

    5. When Zone Light 1 is lit on the keypad the default is com- 5.33 Walk Test (Installer) plete. The Installer Walk Test can be used to test the alarm state of 6. Remove AC power from the control each zone of the panel. The walk test cannot be used to test 7.

  • Page 32: Section 6: Programming Worksheets

    Section 6: Programming Wo rksheets For the Record Customer: _______________________________________________________________________________________________________ Address: ________________________________________________________________________________________________________ Telephone: ___________________________________________ Installation Date: ___________________________________________ Installer’s Code: __________________________________________________________________________________________________ Module Name Description Location PC1565 Main Panel I________________________________________________________________________________________________________________I PC5132 Wireless Receiver I________________________________________________________________________________________________________________I PC5400 Serial Printer Module I________________________________________________________________________________________________________________I GSM1000 Cellular Communicator I________________________________________________________________________________________________________________I LINKS2X50 Long Range Radio...
  • Page 33 Keypad Programming [000] Keypad Enrollment (Section 2.5 “Keypad Assignment” on page 4) NOTE: This must be done at each keypad requiring programming. [0] slot [Valid entries are 11-18; ie. enter [11] for slot 1, [12] for slot 2, etc.] [1] Function Key 1 Assignment (Valid entries are 00-17) [2] Function Key 2 Assignment (Valid entries are 00-17) [3] Function Key 3 Assignment (Valid entries are 00-17) [4] Function Key 4 Assignment (Valid entries are 00-17)
  • Page 34 [005] System Times Default Valid entries: [001-255] Entry Delay for Final Door Set (in seconds) and 5.18 “Entry/Exit Delay Options” on page 24) I_______I_______I_______I Entry Delay (in seconds) and 5.18 “Entry/Exit Delay Options” on page 24) I_______I_______I_______I Exit Delay (in seconds) and 5.18 “Entry/Exit Delay Options” on page 24) I_______I_______I_______I Bell Cut-off (in minutes) and 5.13 “Bell”...
  • Page 35 P r o g r a m m i n g W o r k s h e e t s [014] Second System Option Code Default Option Section Page # For future use I________I Audible Exit with Urgency Silent Exit Delay 5.18 I________I Exit Delay Termination Enabled...
  • Page 36 [020] Keypad Zone Assignments (Section 2.12 “Keypad Zones” on page 6) NOTE:Only one keypad may be assigned to a zone. Default Keypad (slot 1) Zone Valid entries are zones 01-08 I________I_______I Keypad (slot 2) Zone Valid entries are zones 01-08 I________I_______I Keypad (slot 3) Zone Valid entries are zones 01-08...
  • Page 37 P r o g r a m m i n g W o r k s h e e t s Advanced System Programming Zone Attributes (Section 5.3 “Zone Attributes” on page 16) Zone Attribute Defaults (Y = Option ON; N = Option OFF): Attribute: Audible Steady...
  • Page 38 PGM Output Attributes (Section 5.11 “PGM Output Options” on page 21) Program only the following attributes for the PGM Options listed. All others will be ignored. PGM Options are programmed in [009]. PGM Attribute Defaults (Y = Attribute ON; N = Attribute OFF): Attribute: Output enabled —...
  • Page 39 P r o g r a m m i n g W o r k s h e e t s [160] Maximum Dialing Attempts to Each Telephone Number (Section 5.5 “Communicator – Dialing” on page 17) Default: 007 Valid entries are 001-015 attempts (do not enter 000). I_______I_______I_______I [161] Post Dial Wait for Handshake (All Formats) (Section 5.5 “Communicator –...
  • Page 40 [329] Priority Alarm and Restoral (Section 5.8 “Communicator – Reporting Codes” on pg. 18, & Appendix A) Keypad Fire Alarm Keypad Fire Restoral I_______I_______I I_______I_______I Keypad Auxiliary Alarm Keypad Auxiliary Restoral I_______I_______I I_______I_______I Keypad Panic Alarm Keypad Panic Restoral I_______I_______I I_______I_______I PGM2 Alarm PGM2 Restoral...
  • Page 41 P r o g r a m m i n g W o r k s h e e t s [349] Maintenance Alarm Reporting Codes (Section 5.8 “Communicator – Reporting Codes” on pg. 18, & Appendix A) Battery Trouble Alarm Auxiliary Power Supply Trouble Alarm I_______I_______I I_______I_______I...
  • Page 42 [363] Tamper/Restore Communicator Call Directions (Section 5.5 “Communicator – Dialing” on page 17) Default Option 1st Telephone Number Disabled I________I 2nd Telephone Number Disabled I________I 1st Telephone Number (via GSM1000) Disabled I_______I 2nd Telephone Number (via GSM1000) Disabled I_______I For future use I_______I [365] Opening/Closing Communicator Call Directions (Section 5.5 “Communicator –...
  • Page 43 P r o g r a m m i n g W o r k s h e e t s [371] Test Transmission Time of Day (Section 5.14 “Test Transmission” on page 23) NOTE: If the land line test transmission cycle is programmed in minutes (section [702], option [3]), this section will not affect the land line test transmission cycle.
  • Page 44 Downloading Options [401] First Downloading Option Code (Section 5.10 “Downloading” on page 20) Default Option Answering Machine/Double Call Enabled Answering Machine/Double Call Disabled I_______I User Can Enable DLS Window User Cannot Enable DLS Window I_______I Call-Back Enabled Call-Back Disabled I_______I User-initiated Call-up Enabled User-initiated Call-up Disabled I_______I...
  • Page 45 P r o g r a m m i n g W o r k s h e e t s [703] Delay Between Dialing Attempts (Section 5.5 “Communicator – Dialing” on page 17) Default: 001 (Valid entries are 000-255 Seconds) I_________I________I________I Module Programming [801] PC5400 Printer Module Programming...

  • Page 46: Appendix A: Reporting Codes

    Appendix A: Reporting Codes The following tables contain Contact ID and Automatic SIA for- SIA Format - Level 2 (Hardcoded) mat reporting codes. For more information on reporting code The SIA communication format used in this product follows the formats and notes about individual reporting codes, see sec- level 2 specifications of the SIA Digital Communication Stan- tions 5.8 “Communicator –...
  • Page 47 R e p o r t i n g C o d e s Dialer Contact SIA Auto Rep Section # Reporting Code Code Sent When... Direction* ID Codes Codes** [349-350] AC Line Trouble/Rest. AC power to control panel is disconnected or inter- MA/R (3) A1 AT-00/AR-00...

  • Page 48: Appendix B: Programming Lcd Keypads

    Appendix B: Programming LCD Keypads If you have an LCD5500Z v2.2U Keypad, additional programming is required for proper operation. The following is a description of the available programming options and their accompanying programming sections: How to Enter LCD Programming Follow the programming procedure as outlined in Section 4 by pressing [*][8][Installer’s Code]. Press the [*] key. Enter the two digit Section number to be programmed.
  • Page 49 P r o g r a m m i n g L C D K e y p a d s [61] Second User Display Mask Default Option Installer Programming prompt ON Installer Programming prompt OFF I_______I Stay Arm prompt ON Stay Arm prompt OFF I_______I Quick Arm prompt ON...
  • Page 50 ASCII Characters...
  • Page 51 DSC. Custom products                              are only warranted to the extent that they do not function upon delivery. In such cases, DSC can  %                  replace or credit at its option.
  • Page 52 Users can bypass groups of zones (See “[*][1] Bypass- other software versions. ing and Activating Stay/Away Zones” on page 8.) • Bell Trouble inhibits arming Direct all comments concerning this ©2002 Digital Security Controls Ltd. publication to pubs@dscltd.com. Toronto, Canada • www.dsc.com Printed in Canada 29005117 R002...
